User Manual for Paralinx Arrow-X SDI Transmitter Click to enlarge the picture
Contents of the user manual for the Paralinx Arrow-X SDI Transmitter
- Product category: Wireless Transmission Systems Paralinx
- Brand: Paralinx
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Paralinx Wireless Transmission Systems
|
User manual for the Paralinx Arrow-X SDI Transmitter contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Paralinx product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Paralinx user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Paralinx product will considerably shorten its lifespan!
|
Product description The Arrow-X SDI System Transmitter from Paralinx transmits real-time uncompressed Full HD 1080p60 video up to 700' (with the included antennas) for your television, film, broadcast, industrial, or UAV/UAS applications, when used with the Arrow-X SDI System Receiver (available separately). It features 3G-SDI input with loop-through output, and a 2-pin power connector that handles a wide 7 to 17V unregulated input voltage. - Operates in the 5 GHz frequency band
- Real-time viewing (less than 1 ms latency)
- Uncompressed Full HD video signal allows for critical accurate monitoring
- Range of up to 700' with the included antennas
- Longer range possible with separately sold antennas
- Lightweight minimalist design for handheld, Steadicam, gimbal, and UAV payload
- Rugged machined aluminum enclosure
UPC: 788490310914 In the Box Paralinx Arrow-X SDI Transmitter 2 x Antenna Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Paralinx Arrow-X SDI Transmitter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersParalinx 10-1237 Specs | Frequency Band | 5 GHz | | Transmit Range | 700' (213 m) | | Input | 3G-SDI with loop-out | | Power Connector | 2-pin female
Supports 7 to 17 V unregulated input | | Material | Enclosure: Aluminum | | Compliance | FCC, CE, MIC (TELEC), and RoHS | | Dimensions | 4.3 x 2.6 x 0.8" (108 x 67 x 21 mm) without antennas | | Weight | 6.3 oz (178 g) without antennas | | | | Package Weight | 1.3 lb | | Box Dimensions (LxWxH) | 8.6 x 6.8 x 3.5" |
