Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof

Search your instruction manual in PDF to download

User Manual for Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof PTZ Network Bullet Camera with IR Illuminators

Click to enlarge the picture
Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof PTZ Network Bullet Camera with IR Illuminators Contents of the user manual for the Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof
  • Product category: Wired IP Cameras Pelco
  • Brand: Pelco
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Pelco Wired IP Cameras

User manual for the Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Pelco product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Pelco user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Pelco product will considerably shorten its lifespan!



Product description

The ExSite Enhanced EXP1230-7M 2.1MP Explosionproof PTZ Network Bullet Camera from Pelco can record 1920 x 1080 video at up to 60 fps. A 4.3-129mm lens provides 30x optical zoom and an IR LED provides night vision for up to 656'. A microSD card slot supports up to 2TB of local storage (available separately). This camera is designed for use in dangerous environments including oil and LNG facilities, refineries, on and offshore drilling rigs, and onboard marine applications. It has dual entry ports, allowing for separate transmission and power cable, and is adaptable to most transmission methods via SFP/FSFP modules. This camera comes with a wiper and a sun shroud so it can capture video regardless of the weather.
  • Rugged 316L stainless steel construction for extreme conditions of temperature, moisture, ice, and dust
  • System can operate from -76 to 140°F while maintaining compliance to the T6 surface temperature specifications
  • Dual stream H.264 IP video with smart compression
  • SureVision 3.0 technology
  • 130 dB wide dynamic range and low-light imaging performance down to 0.03 lux
  • Image defog capability increases video quality in poor visibility conditions
  • Antibloom, 3D noise filtering, and enhanced tone mapping
  • Upright or inverted installation with automatic orientation detection
  • Low latency electronics for improved pan/tilt drivability and safety
  • Standard IP Ethernet connection and integrated transmission options including fiber, Ethernet-over-coax, and UTP extension
  • Electronic image stabilization
  • Efficient installation with a safety attachment point and simple wire termination methods
  • Built-in analytics
  • Integrated wiper
  • Sun shroud and heater/window defroster
  • Configurable onscreen displays
  • Autofocus with manual override
  • Auto iris with manual override
  • Dual cable entries for multiple data and power configurations
  • Compatible with third-party explosionproof wash systems
  • Direct drive motor control automatically accommodates for high vibration and windy environments to ensure continuous precision control
  • Keeps position and executes PTZ commands even in high wind conditions such as hurricanes or tropical storms
  • Alarms can be individually configured for three priority levels, to initiate a stored tour, or to go to an associated preset when received
  • Continually decreases pan and tilt speeds in proportion to depth of zoom
  • Auto Flip supports operation when mounted in an inverted position
  • Remote hard-reset capability allows for maintenance without physical access to the camera
  • Multilingual menus
UPC: 700880339619 In the Box Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof PTZ Network Bullet Camera with IR Illuminators
  • Limited 3-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Pelco ExSite Enhanced EXP1230-7M 2.1MP Explosionproof PTZ Network Bullet Camera with IR Illuminators in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Pelco ExSite Enhanced PTZ Specs

    Sensor 2.1 MP 1/2.8" CMOS
    Focal Length 4.3 to 129mm
    Maximum Aperture f/1.6 - f/4.7
    Zoom Optical: 30x
    Digital: 12x
    Lens Field of View Horizontal: 63.7 to 2.3°
    IR Cut Filter Mechanical
    Day/Night Yes
    Minimum Illumination Color: 0.008 Lux
    B&W: 0.001 Lux
    Shutter Speed 1/10,000 to 1 Seconds
    Streaming Resolution 1920 x 1080 at 60 fps (8 Mb/s )
    Supported Video Compression H.264, MJPEG
    Multi-View Streaming Yes, 2 Streams
    Automatic Gain Control Yes
    Security HTTPS, IEEE 802.1X, Password Protection
    Supported Protocols DHCP, DNS, FTP, HTTP, IGMP, IPv4/v6, NTP, ONVIF Profile G, ONVIF Profile Q, ONVIF Profile S, QoS Layer 3 DiffServ, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSH, SSL/TLS, TCP, UDP, UPnP
    Application Programming Interface (API) FSFP, Third-Party MSA-Compliant, ONVIF
    Analytics Abandoned Object, Adaptive Motion Detection, Camera Sabotage, Directional Motion, Loitering Detection, Object Counting, Object Removal, Stopped Vehicle
    Event Trigger Yes
    Event Action Recording, Notification, Alarm
    Recording Media microSD (Up to 2000 GB)
    Pan/Tilt Programmed Pan: 360° at 200°/s
    Programmed Tilt: 180° (-90 to 90°) at 200°/s
    Alarm I/O 4 / 2
    I/O Connections 1 x RJ45
    2 x SFP
    1 x Power
    IR Illuminators 1 x 850 nm
    IR Range 656.17' / 200 m
    Internal Storage None
    External Storage Options Local PC
    Power Source AC
    Power Consumption AC: 211 W
    AC: 148 W (With Heater)
    Material of Construction Stainless Steel
    Operating Temperature -76 to 140°F / -60 to 60°C
    Storage Temperature -76 to 140°F / -60 to 60°C
    Operating Humidity 10 to 100%
    Dimensions H: 18.9 x W: 10.5" / H: 48.0 x W: 26.7 cm
    Weight 89 lb / 40.4 kg
