User Manual for Philips BDM4350UC Brilliance 43" 4K IPS Display Click to enlarge the picture
Contents of the user manual for the Philips BDM4350UC Brilliance 43" 4K IPS
- Product category: Computer Monitors Philips
- Brand: Philips
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Philips Computer Monitors
 |
User manual for the Philips BDM4350UC Brilliance 43" 4K IPS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Philips product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Philips user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Philips product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More Experience 4K with the BDM4350UC Brilliance 43" 4K IPS Display from Philips. This monitor is built with an In-Plane Switching (IPS) display that provides you with wide 178° viewing angles and vivid colors. Its 3840 x 2160 4K UHD resolution provides crisp and clear images and allows you to multitask easily with up to four Full HD displays at once. Furthermore, it supports 1.07 billion colors, has a 300 cd/m² brightness rating, and a 1200:1 static contrast ratio, which provides you with darker blacks and brighter bright colors for a more immersive viewing experience. Connect this display to your system via VGA, HDMI, or DisplayPort and adjust it to your viewing preference. Otherwise, install an alternate stand or mount using the VESA mounting holes on the back. - UltraClear 4K UHD Resolution
- A 4K Ultra HD panel has a resolution of 3840 x 2160, which can deliver extremely detailed images for CAD solution, provide ample real estate for huge spreadsheets, and simplify multitasking with side-by-side windows.
- IPS Technology
- Constructed with an In-Plane Switching (IPS) panel, the BDM4350UC gives you extra wide 178° viewing angles so you can view it from almost any position. It also provides you with crisp images and vivid colors making it ideal for photos, movies, web browsing, as well as color sensitive work.
- MultiView Technology
- Philip's MultiView technology lets you have up to four systems, each shown in Full HD, on one screen. You can even use the Picture-by-Picture (PbP) function for monitoring four systems at once on one screen.
- SmartUniformity
- Philip's SmartUniformity mode delivers accurate images with uniform brightness, which is crucial for photography, design, and printing. With a color metric to assess color accuracy, this mode is calibrated to meet average luminance uniformity of greater than 95%. Selecting this mode will produce uniform and accurate images.
- SmartImage
- SmartImage analyzes the content displayed on your screen and delivers and optimized viewing experience. You can select various modes such as office, photo, movie, game, economy, and more to fit the application in use. Based on what you choose, SmartImage dynamically optimizes the contrast, color saturation, and sharpness of images and videos.
- Built-In Audio
- The Philips BDM4350UC monitor has two built-in 7W speakers as well as audio in and out jacks. If you have third party speakers or if you need some privacy with headphones, use the audio in/out jacks to connect your own peripherals and devices.
- USB 3.0 Hub
- Four USB 3.0 Type-A ports allow you to quickly and easily transfer data from your mobile devices at speeds of up to 5 Gb/s. Furthermore, one of the ports feature fast charging so you'll be able to charge your device faster.
UPC: 609585249608 In the Box Philips BDM4350UC Brilliance 43" 4K IPS Display Limited 3-Year Warranty Data Sheet PDF 900.6kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Philips BDM4350UC Brilliance 43" 4K IPS Display in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPhilips BDM4350UC Specs | | | Size | 42.5" | | Screen Area | 37.5 x 21.4" / 95.3 x 54.3 cm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 3840 x 2160 | | Contrast Ratio | 1200:1 | | Dynamic Contrast Ratio | 50,000,000:1 | | Refresh Rate | 60 Hz | | Adaptive Sync Technology | None | | Horizontal Frequency | 30 to 99 kHz | | Vertical Frequency | 23 to 80 Hz | | Bit Depth / Color Support | 10-Bit (1.07 Billion Colors) | | Response Time | 5 ms | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.2451 x 0.2451 mm | | Backlight Lifespan | 70,000 Hours | | | | Connectivity | 1 x 3.5 mm Input/Output
1 x 3.5 mm Output
4 x USB Type-A (USB 3.1 Gen 1) Output
2 x DisplayPort Input
2 x HDMI 2.0
1 x VGA | | Built-In Speakers | Yes, 2 x 7 W | | | | Power Consumption | 46.5 W (Eco)
0.5 W (Standby)
100 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | Internal | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Operating Humidity | 20 to 80% | | Operating Altitude | 0 to 12,000' / 0 to 3658 m | | Storage Altitude | 0 to 40,000' / 0 to 12,192 m | | Certifications | ENERGY STAR, RoHS, WEEE, as per Manufacturer | | | | Mounting-Hole Pattern | 200 x 200 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 38.1 x 24.8 x 10.2" / 96.8 x 63.0 x 25.9 mm (With Stand)
28.1 x 22.1 x 3.2" / 96.8 x 56.2 x 8.2 mm (Without Stand) | | Weight | 20.7 lb / 9.4 kg (Without Stand)
21.4 lb / 9.7 kg | | | | Package Weight | 31.5 lb | | Box Dimensions (LxWxH) | 42.3 x 26.3 x 6.5" |
Rating78% users recommend this product to others. And what about you?
This product has already been rated by 33 owners. Add your rating and experience with the product.
