User Manual for Philips PocketMemo Digital Meeting Recorder Click to enlarge the picture
Contents of the user manual for the Philips PocketMemo Digital Meeting Recorder
- Product category: Handheld Voice Recorders Philips
- Brand: Philips
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Philips Handheld Voice Recorders
 |
User manual for the Philips PocketMemo Digital Meeting Recorder contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Philips product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Philips user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Philips product will considerably shorten its lifespan!
|
Product description The PocketMemo Digital Meeting Recorder from Philips features an extendable 360° microphone system that offers flexibility as well as ease of use. You can extend the recording range of your recorder by simply connecting up to six meeting microphones. The boundary layer design of the included meeting microphones uses the sound pressure of the table to provide good sound and recording quality with a 360° sound pickup radius. The built-in wire storage in the 360° microphones allows you to adjust the length of the cable.
The SpeechExec software organizes the workflow of dictation files and resulting documents, allowing you to monitor the status of your work. When plugged in, the PocketMemo voice recorder automatically downloads your audio files directly onto the computer. It features a 1000mAh lithium-ion ACC8100 battery that can be charged in 3 hours. - Records in DSS Pro, MP3, and PCM formats
- Metal carrying case for portability
- Exchangeable memory card for unlimited recording
- Expandable through cascading
- Features author ID setting, file lock, and priority setting
- Memory card slot (supports up to 32GB)
- Transfers data at 6.75 MB/s (read) and 5.0 MB/s (write)
- Edit Modes: Insert (DSS/DSS Pro), overwrite (DSS/DSS Pro, MP3, PCM), and append (DSS/DSS Pro, MP3, PCM)
- Less than 200mW speaker output power
- Built-in round, dynamic speaker
- More than 200 days standby time
- Battery charges fully in 3 hours
- Lead-free soldered device is 2011/65/EU (RoHS) compliant
- Operates at 41 to 113°F and 10 to 90% humidity (non-condensing)
- Microphone
-
- Design: Boundary layer microphone
- Type: Electret condenser microphone
- Impedance: Approximately 2.2 kOhms @ 1 kHz
- Sensitivity: -38 dBV
- Frequency Response: 30 to 18,000 Hz
- Phantom Supply Voltage: 1.5–5 V/0.5 mA
- Connector: 3.5m
- Audio Jack (for cascading): 3.5mm
- Cable Length: 6.5’ (2m)
- Dimensions: 5.1 x 5.1 x 0.7” (13.0 x 13.0 x 1.8 cm)
- Weight: 3.8 oz (108 g)
In the Box Philips PocketMemo Digital Meeting Recorder Pocket Memo Docking Station for Philips DPM8000, DPM7000, and DPM6000 Series Dictation Recorders 4 x Conference Microphone 9172 ACC8100 Rechargeable Li-ion Battery for Philips DPM8000, DPM7000, and DPM6000 Series Dictation Recorders Memory Card Power Supply Remote Control USB Cable Splitter Cable Pouch SpeechExec Dictation Software Metal Carry Case Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Philips PocketMemo Digital Meeting Recorder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPhilips DPM8900 Specs | | | Type | Digital | | Mode | Stereo / Mono | | Recording Format | Digital Speech Standard (DSS), MP3, PCM (WAV) | | Bit-Rate | 13.7 kbps
28 kbps
192 kbps
353 kbps
705 kbps | | Sample Rate | 44.1 kHz
22.05 kHz
16 kHz
12 kHz | | Recording Time | SP Mono: 700 Hours
QP Mono: 350 Hours
MP3 Stereo: 50 Hours Recording in MP3 Format
PCM: 27 Hours
PCM Stereo: 13 Hours | | One-Click Recording | Yes | | Voice Activated Recording | Yes | | Microphone Type | Internal Stereo - 4 Elements | | Pickup Pattern | Omni-Directional | | Frequency Response | 300 Hz - 7500 Hz | | | | Playback Formats | MP3 | | Speaker | Yes | | Speaker Size | 1.1" / 28 mm 28 mm diameter | | | | Display Size/Type | 2.4" TFT with 320 x 240 Resolution | | Safety Lock | Yes | | | | Battery Type | x Rechargeable Lithium-Ion Battery Pack | | Battery Life (approx.) | Recording: 30 Hours | | Power Adapter | Yes | | | | Compatible Memory Cards | SDHC
SD | | Connectors | 1/8" mini Microphone
1/8" mini Headphone | | USB | USB 2.0 (Micro-B) | | Operating System Support | Windows | | Dimensions (WxHxD) | 2.1 x 4.8 x .6" / 53.34 x 121.92 x 15.24 mm | | Weight | 4.1 oz / 116 g Including battery and memory card | | | | Package Weight | 9.0 lb | | Box Dimensions (LxWxH) | 19.55 x 13.0 x 6.0" |
