Photogenic StudioMax III Pro Monolight Kit

User Manual for Photogenic StudioMax III Pro Monolight Kit

• Product category: Monolights Photogenic
• Brand: Photogenic
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Photogenic Monolights

Product description

• Photogenic AKC160 Studiomax III 160W/s Monolight The Photogenic AKC160 Studiomax III 160W/s Monolight is an ideal way to add a lightweight (2.6 lb) fixture to your kit for a main light, backlight or fill light. The AKC160 offers a six stop power range from 5.0 to 160W/s, steplessly adjustable via a simple knob. Constant Color technology ensures that the color balance remains within 200K of an ideal 5,400K regardless of the power level chosen, to insure shot to shot consistency and minimize post-production work. The AKC160 comes with a UV color corrected, user-replaceable flash tube that renders fabrics and flesh tones accurately. The monolight comes with a 7.5" high-gain reflector but accepts the entire line of Photogenic Quick-Change reflectors, grids, snoots, and diffusers. An AC cord, sync cord, 100W quartz modeling lamp and a protective cap are also included.
  Six Stop Power Range
  • Power levels, accessed on the rear panel, are adjustable from 5.0 to 160W/s with a simple twist of a knob
  Fast Recycling
  • The AKC160 recycles to full power (160W/s) in only 1.5 seconds, and 0.5 sec. at minimum power to catch even the most fleeting gestures
  Modeling Light
  • The AKC160's 100W quartz modeling light allows you to preview the effect of your lights before tripping the shutter
  Low Trigger Voltage
  • Digital cameras can be used with Photogenic monolights without fear of damage to the camera's electronics
  User Replaceable UV Flashtube
  • Replacing this "plug & play" flashtube is a snap. The UV coating ensures clean whites and flattering flesh tones
  Ready Indication
  • A ready light lets you know when the flash is fully charged
  Power off Auto-discharge
  • As a safety precaution, the AKC160 drains the capacitors when you turn it off
  Surge Protection
  • The AKC160 incorporates surge protection to handle power spikes
  System Compatibility
  • The AKC160 is compatible with all Photogenic Quick-Change light shaping accessories
  UPC: 689670111195
• Impact White Translucent Umbrella (43") Umbrellas soften, broaden, and diminish the light output of any flash light source. Umbrellas with a white interior will soften and weaken light more than an umbrella with a silver lining. A white umbrella without a black backing may also be used as a makeshift softbox, although the use of the light will not be as efficient as with a lightbox.Choosing umbrella size is determined by the size of the subject, and the strength of the light supply being used. Choosing an umbrella surface is as subjective as choosing a paint and brush.This Impact 43" White Translucent Umbrella is suggested for use in mid-length portraits for one or two persons. UPC: 847628013292

• AKC160 Studiomax III 160W/s Monolight ezfbwwyccuzardctfsuwvayc
• ESR (100W/120V) Lamp
• 7-1/2" High Gain Reflector
• C4-12C Color Corrected Flash Tube
• AC Line Cord - 110V, for PL and PM
• Protective Cap for Powerlight
• PC to Mini Sync Cord - 10' (3m)
• Limited 1-Year Warranty

• Impact - Umbrella - White Translucent (43")

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Photogenic AKC160 Studiomax III 160W/s Monolight

  Maximum Power	5 to 160 Ws
  Power Control	6 Stops
  Guide Number	25' / 7.6 m at 10' / 3 m, ISO100 81' / 24.7 m at 10' / 3 m, ISO100 with Reflector
  Flash Duration	1/7400 to 1/175 Sec
  Recycle Time	0.1 to 1.5 Sec ()
  Color Temperature	5400K ± 200K
  Flash Ready Indicator	Visual
  Reflector	Changeable
  Accessory Fitting Type	Photogenic

  Type	Tungsten
  Wattage	100 W

  Sync Type	Optical
  Interface	PC Sync (3.5 mm)
  Sync Voltage	5 V

  AC Input Voltage	105to125 VAC, 60 Hz
  Current	3 A (Operating) 5 A (Charging) 1 A (Idle)
  Circuit Protection	Fuse
  Fuse	8 A

  Display	None
  Mount	5/8" / 16 mm Receptacle
  Auto Dump	No
  Fan Cooled	No
  Dimensions	H: 5.2 x W: 5.2 x L: 7.0" / H: 13.3 x W: 13.3 x L: 17.8 cm
  Weight	2.6 lb / 1.17 kg

  Box Dimensions (LxWxH)	12.8 x 10.35 x 10.2"

• Impact White Translucent Umbrella (43")

  Size	43.0" / 109.2 cm
  Interior	White (Translucent)
  Shaft Diameter	8 mm
  Folded Size	L: 28.3" / L: 71.8 cm

  Box Dimensions (LxWxH)	29.0 x 2.7 x 1.65"
