User Manual for Platinum Tools 13120 Opti-E Punchdown Tool Click to enlarge the picture
Contents of the user manual for the Platinum Tools 13120 Opti-E Punchdown Tool
- Product category: Installation & Maintenance Tools Platinum Tools
- Brand: Platinum Tools
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Platinum Tools Installation & Maintenance Tools
|
User manual for the Platinum Tools 13120 Opti-E Punchdown Tool contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Platinum Tools product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Platinum Tools user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Platinum Tools product will considerably shorten its lifespan!
|
Product description The Platinum Tools 13120 Opti-E Punchdown Tool is designed to optimize the force applied to the termination by way of electronics. The internal electronics, powered by a 9 V battery, is designed to let the technician know by both an LED and a beep tone that the selected set force has been reached. The force is selected by turning the force selector wheel on the front of the tool. The Opti-E Punchdown Tool has no impact. It is a smooth, non-aggressive method of punching down reducing damage to sensitive circuitry. This type of design is referred by some as the soft punch, as it reduces the potential of repetitive stress injuries. - Bayonet style (twist & lock) blade retention socket is compatible with industry standard blades
- 110-, 66-, 630-, Krone-, and BIX-style interchangeable blades
- Adjustable force settings can be precisely controlled
- Will not damage sensitive circuitry
- Use to terminate and trim wires in 66-, 110-, Krone-, & BIX-style cross connect blocks
- Use to terminate and trim wires in 110- & 630-style wall jack modules
UPC: 849160000273 In the Box Platinum Tools 13120 Opti-E Punchdown Tool 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Platinum Tools 13120 Opti-E Punchdown Tool in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPlatinum Tools 13120 Specs | Power | Powered by: 9 V battery | | Dimensions | 6 x 1.5" (152.4 x 38.1 mm) | | Weight | With Battery: 5.8 oz (164.43 g) |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 29 owners. Add your rating and experience with the product.
