User Manual for PortaCom BP-500L Listen-Only Beltpack for ProLink 500 Intercom Click to enlarge the picture
Contents of the user manual for the PortaCom BP-500L Listen-Only Beltpack for ProLink
- Product category: Wired Intercoms PortaCom
- Brand: PortaCom
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for PortaCom Wired Intercoms
|
User manual for the PortaCom BP-500L Listen-Only Beltpack for ProLink contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any PortaCom product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official PortaCom user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a PortaCom product will considerably shorten its lifespan!
|
Product description The BP-500L Listen-Only Beltpack for ProLink 500 Intercom from Anchor Audio/Porta-Com is a listen-only beltpack for use as part of a ProLink 500 intercom system. The beltpack features a compact and portable design and offers operation without the need for a base station. A full ProLink 500 system can support 1 BP-500 master beltpack, up to 3 remote beltpacks, and an unlimited number of listen-only beltpacks for clear communication at distances up to 500' away. The beltpack has an LED indicator that flashes red when it is out of range from the master beltpack.
The BP-500L has an A/B channel selector and a power/volume knob to precisely adjust the operation to meet your needs. The beltpack has a 4-pin XLR headset connector for use with Anchor Audio headsets, or any headset with a dynamic microphone. It also has Bluetooth technology, which allows you to use a Bluetooth wireless headset up to 10' away from the beltpack. The beltpack operates on a set of 3 AA rechargeable batteries and has a charging port for quick charging in the separately-available gang charger. Note: A BP-500 master beltpack, sold separately, is required to create a system. - Compact and portable design
- Operates without the need for a base station
- Works in the 902-928MHz frequency band, and no FCC license is required
- Provides listen-only communication with master and remote beltpacks for clear audio at distances up to 500' away
- There are power/low battery and out-of-range LED indicators
- There is an A/B channel selector and a power/volume knob to precisely adjust the operation to meet your needs
- 4-pin XLR headset connector for use with Anchor Audio headsets, or any headset with a dynamic microphone
- Bluetooth technology lets you use a Bluetooth wireless headset up to 10' away from the beltpack
- Operates on a set of 3 AA rechargeable batteries and has a charging port for quick charging in the separately-available gang charger
UPC: 643906939939 In the Box PortaCom BP-500L Listen-Only Beltpack for ProLink 500 Intercom 3 x Rechargeable AA Batteries 2-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the PortaCom BP-500L Listen-Only Beltpack for ProLink 500 Intercom in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersPortaCom BP-500L Specs | RF Frequency Range | 902-928MHz | | Modulation | FSK | | Range | Up to 500' (152.4 m) (Line of Sight) | | Antenna | 1/2 Wavelength Dipole | | Power | 9VDC, 1.2ADC (3 x AA Batteries)
Up to 12 Hours of Operation | | Dimensions (HxWxD) | 4.5 x 6.25 x 3.75" (114 x 159 x 95mm) | | Weight | 15 oz (0.42kg) (With Batteries) | | | | Package Weight | 0.95 lb | | Box Dimensions (LxWxH) | 7.638 x 6.614 x 2.835" |
