Proavio DS320 64TB 16-Bay Fibre Channel

Search your instruction manual in PDF to download

User Manual for Proavio DS320 64TB 16-Bay Fibre Channel RAID Array with Dual-Active Controllers

Click to enlarge the picture
Proavio DS320 64TB 16-Bay Fibre Channel RAID Array with Dual-Active Controllers Contents of the user manual for the Proavio DS320 64TB 16-Bay Fibre Channel
  • Product category: Hard Drive Arrays Proavio
  • Brand: Proavio
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Proavio Hard Drive Arrays

Proavio DS320 64TB 16-Bay Fibre Channel RAID Array with Dual-Active Controllers Proavio DS320 64TB 16-Bay Fibre Channel RAID Array with Dual-Active Controllers
User manual for the Proavio DS320 64TB 16-Bay Fibre Channel contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Proavio product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Proavio user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Proavio product will considerably shorten its lifespan!



Product description

RAID Arrays for Photography and Pro Video Read More The DS320 64TB 16-Bay Fibre Channel RAID Array (16 x 4TB) from Provaio continuously delivers up to 64TB of media data via two active-active RAID controllers. This array is suitable for post-production environments such as a SAN or a direct-attached storage solution by utilizing its four high-speed 16 Gb/s SFP Fibre Channel optical ports on two controllers. With the included sixteen 4TB 7200 rpm SAS 3.5" hard drives, it transfers data at a rate of up to 3,500 MB/s when the drives are configured into a RAID 5 array. In addition to RAID 5, the RAID controller supports RAID 0, 0 + 1, 6, and JBOD.

Provaio has designed this array with sixteen bays that support 2.5" and 3.5" hard drives or SSDs. You can connect optional expansion units via its SAS Expansion bus port to access up to 80 total drives, including the base unit. It features a 3RU form factor and includes 16GB of RAM. There is also support for network configurations such as VMware, Xsan, and more.

This storage array comes equipped with redundant hot-swappable modules that offer power and cooling with dual 500W power supplies and smart cooling fans. This feature provides redundancy and reliability for critical and intensive data applications. Another notable feature is compatibility with Thunderbolt-to-FC bridging technologies to add support for both Fibre Channel and Thunderbolt users.

General Features

    Storage Solution for 4K Media
  • The DS320 features an easy-to-use hardware design, which allows users to spend more time being creative and less time optimizing computer technology to meet their workflow demands. Empower your workstation with the speed and reliability needed for today's high-resolution post-production and VFX workflows. Achieve smooth, real-time playback of complex visual effects compositions, preview projects at full native resolution, and gain higher track counts in the edit process—all while enjoying fail-safe RAID protection of your digital assets.
    Optimized for High-Resolution Workflows
  • With a sustained throughput of over 3,500 MB/s (RAID 5), the DS320 unlocks your workstation's creative potential by giving facilities the option to take on a wide range of projects, formats, and possibilities. From HD to 4K, the DS320 is a suitable storage solution for high-resolution media formats such as DPX, RED R3D, ARRIRAW, Arri Alexa, uncompressed HD, DSLR RAW, and more.
    Active-Active, Enterprise-Class Storage Solution
  • The DS320 incorporates RAID technology with active-active storage engines that deliver unimpeded performance and reliability.
    Thunderbolt-Ready Solution
  • Proavio offers instant compatibility with Apple and Thunderbolt equipped systems. DS320 users can take full advantage of Proavio SAS storage solutions for optimal reliability or performance with an optional external FC-to-Thunderbolt adapter.
In the Box Proavio DS320 64TB 16-Bay Fibre Channel RAID Array with Dual-Active Controllers (16 x 4TB)
  • Limited 3-Year Warranty
