Product description QSC PA Speakers Buying Guide Read More The AcousticPerformance Series Loudspeaker from QSC is a professional, two-way, full-range loudspeaker ideal for a variety of portable and installed sound reinforcement applications requiring high power, wide coverage and compact size. The speaker uses a 12” woofer with 2.5” voice-coil and a coaxially mounted high power-capacity, 1.75” voice coil compression driver to deliver full bandwidth reproduction. The uniform power-response of the speaker is a result of DMT (Directivity Matched Transition), a design philosophy which matches the HF waveguide to the natural conical coverage of the woofer at the cross-over point. The result is a remarkably consistent coverage with smooth, accurate reproduction both on and off-axis. To further enhance system performance and speed of install with optimum result, proprietary Intrinsic Correction tunings are obtainable via Q-SYS networked audio processing platforms, including CXD and PLD amplifiers for a complete QSC systems solution.The speaker’s enclosure is of 15mm Baltic Birch plywood construction, designed for versatile deployments. The multipurpose enclosure features both 60° and 40° angles for use as floor monitors, M10 mounting points for suspension via eye-bolts or optional yoke bracket, top handle, and a tilt direct pole cup. Presenting a clean, unobtrusive look, AcousticPerformance grilles are unadorned eliminating the need to cover-up logo treatments which can be difficult to hide or remove. The grille is lined with acoustically transparent backing to maintain the enclosure’s professional appearance. The loudspeaker’s recessed input cup features two NL4 connectors for convenient input and pass through. -
- DMT (Directivity Matched Transition) ensures smooth, coherent power response across the listening plane
- 90° conical coverage matches the natural coverage of the 12” woofer at the crossover point for consistent power response
- Coaxial mounted 1.75” voice coil compression driver for outstanding high-frequency performance
- Multipurpose deployments - dual angle monitor, flown, yoke, or pole
- Clean industrial design with unadorned grilles compliment most decors and settings
- Two NL4 Speakon connectors for input and pass thru
- 15mm Baltic birch plywood construction
- 16-Gauge powder coated steel grilles
UPC: 684284066862 In the Box QSC AcousticPerformance Series Loudspeaker (Black) Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the QSC AcousticPerformance Series Loudspeaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersQSC AP-4122M Specs | Frequency Response | Effective Frequency Range: 55 Hz to 20 kHz
(Free-field, -10 dB from on-axis sensitivity) | | Noise Power | Continuous: 325 W
36 V
(AES2-1984 noise signal for 2 hour) | | Maximum Sound Pressure Level (SPL) | Continuous: 121 dB at 1 m
Peak: 127 dB at 1 m
(Calculated from rated noise voltage and sensitivity) | | System Sensitivity | 96 dB, 1 W @ 1 m
(Free-field, on-axis, 1 W, 1 m) | | Coverage Angle | 90° Conical DMT | | Impedance | 4 Ohms | | Low Frequency Driver | 12" (305 mm) weather resistant cone woofer
2.5" (64 mm) | | High Frequency Driver | 1" (25 mm) compression driver
1.75" (45 mm) voice-coil | | Enclosure Material | 15 mm baltic birch plywood
Grille: 16 gauge powder coated steel | | Input Connections | 2 x NL4 in parallel, 2+/- thru | | Threaded Connector | 11 x M10 threaded inserts | | Dimensions | 20.1 x 15.1 x 14.5" (510 x 385 x 370 mm) | | Weight | 39.7 lb (18.1 kg) | | | | Package Weight | 47.3 lb | | Box Dimensions (LxWxH) | 22.0 x 19.0 x 19.0" |
