User Manual for QSC ADS282HT 8" 2-Way Loudspeaker Click to enlarge the picture
Contents of the user manual for the QSC ADS282HT 8" 2-Way Loudspeaker
- Product category: PA Speakers QSC
- Brand: QSC
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for QSC PA Speakers
|
User manual for the QSC ADS282HT 8" 2-Way Loudspeaker contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any QSC product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official QSC user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a QSC product will considerably shorten its lifespan!
|
Product description QSC PA Speakers Buying Guide Read More The AcousticDesign ADS282HT 8" 2-Way Loudspeaker (Black) is a full-range, contemporary design, weather-resistant loudspeaker with a wide variety of applications. This speaker incorporates the Advanced Directivity Rotatable Waveguide. This proprietary feature gives you focused sound no matter in which direction you choose to mount your speakers. With the included yoke mount bracket you can choose between horizontal and vertical orientations, and then aim it for a perfect audio experience. This entire system is housed in a durable, weather-resistant, injection-molded polystyrene enclosure to give you the best protection possible for your valuable equipment. - Weather Resistant
- The injection-molded polystyrene housing protects your equipment from external damage and environmental influences. It's also attractively finished in a heavy-duty, black powder-coated aluminum grill.
- Versatile Mounting Options
- Mount your loudspeaker in either a horizontal or vertical orientation with the included yoke mount bracket, then aim it to provide the best audio presentation possible.
- 2-Way System
- This 2-Way system features two 8" LF transducers with heavy-duty, double-roll cloth surrounds and a 1" exit compression HF driver, coupled with the unique Advanced Directivity rotatable waveguide.
- Advanced Directivity
- This proprietary feature lets your loudspeaker deliver accurately focused sound no matter how you decide to mount it.
- Transformer Version
- This transformer version contains taps for both 70V and 100V distributed system use.
UPC: 684284047014 In the Box QSC ADS282HT 8" 2-Way Loudspeaker (Black) Yoke Mount Bracket Product Instructions 3-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the QSC ADS282HT 8" 2-Way Loudspeaker in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersQSC AD-S282HT Specs | | | Configuration | Passive 2-Way | | Total Power Capacity | 450 W RMS | | System Impedance | 8 Ohms | | | | HF Driver | 1 x Compression Driver with 1" / 25.4 mm Throat | | LF Driver | 1 x 8" / 20.3 cm Woofer | | | | Frequency Response | 80 Hz to 27.7 kHz | | Maximum SPL | 125 dB | | Speaker Sensitivity | 93 dB | | | | Audio I/O | Barrier Strip Switchable: passive/active on AD-S282H | | | | Construction Material | Metal Grille, Polystyrene | | Dimensions | 10.2 x 26.2 x 11.4" / 259.0 x 685.0 x 290.0 mm | | Weight | 27.7 lb / 12.6 kg | | | | Package Weight | 41.2 lb | | Box Dimensions (LxWxH) | 30.5 x 17.0 x 14.55" |
