Product description The THX Test Pattern Package for 804/804A Video Test Generator from Quantum Data is a software pack which includes both standard definition aspect ratio and high definition aspect ratio patterns. This test pattern pack is an optional addition to the Quantum Data 804/804A video test generator test patterns. The patterns include bitmap test images for calibrating the luminance and chrominance of high end 3D capable HDTVs.
The THX pattern images are stored within the 804/804A video generator and are unlocked by means of a software license key received upon purchase. - 3D Covergence
- Test patterns to align pixels for proper covergence
- 3D Crosstalk
- Test patterns to determine level of 3D crosstalk
- Color Gamut
- 2D/3D primary and secondary color patterns to fine-tune colors and gamma
- Picture Performance
- Pattern within THX Optimizer to verify accuracy of skin tones
- THX Optimizer
- Test patters to easily adjust brightness, contrast, color, tint, etc
- THX Box
- 2D/3D gray-scale test patters to accurately adjust white point and gamma
