User Manual for QVS VC5-1P VGA QXGA Video over CAT5e Single-Power Extender Kit Click to enlarge the picture
Contents of the user manual for the QVS VC5-1P VGA QXGA Video over
- Product category: Video Extenders & Repeaters QVS
- Brand: QVS
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for QVS Video Extenders & Repeaters
|
User manual for the QVS VC5-1P VGA QXGA Video over contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any QVS product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official QVS user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a QVS product will considerably shorten its lifespan!
|
Product description The VC5-1P VGA/QXGA Video over CAT5e Single-Power Extender Kit from QVS extends video signals up to 262' away via a CAT5e cable. It includes a transmitter unit and a receiver unit, a power adaptor, and a 3' HD15 M/M cable. This extender kit provides equalization and video signal gain adjustment. It supports resolutions of 2048 x 1536/60 Hz for up to 164' and 1280 x 1024/60 Hz for up to 262' away. It can be powered from either the transmitter or receiver module. This extender kit connects any VGA/QXGA video display to any computer, projector, LCD, switch, or distribution amplifier. - Transmit video using a CAT5e/6 cable
- Powered from either the transmitter or receiver module
- Receiver module provides equalization and gain controls
- Supports VGA/QXGA up to 2048 x 1536 @ 60 Hz
- FCC, CE and RoHS compliant
UPC: 037229007299 In the Box QVS VC5-1P VGA/QXGA Video over CAT5e Single-Power Extender Kit Power Adaptor Table of Contents
|
Upload User Manual
Have you got an user manual for the QVS VC5-1P VGA QXGA Video over CAT5e Single-Power Extender Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersQVS VC5-1P Specs | Signal Type | VGA/SVGA, XGA/UXGA | | Distance | Up to 262' (80 m) | | Video Bandwidth | Up to 150 MHz | | Connectors | Transmitter:
1 x 15-pin Sub-D, VGA input
1 x RJ45
Receiver:
1 x 15-pin Sub-D, VGA output
1 x RJ45 | | Compatibility | PC & LCD | | Insertion Loss | < 3 dB | | Impedance | RGB: 75 ohms, unbalanced
CAT5e: 100 ohms, balanced | | Video Signal Return Loss | -15 dB max from DC to 60 MHz | | Cable Equalization | CAT5e: Adjustable EQ controls | | Operating Temperature | 32 to 131°F (0 to 55°C) | | Certification and Compliance | RoHs, FCC, and CE | | | | Package Weight | 1.543 lb | | Box Dimensions (LxWxH) | 9.6 x 6.1 x 2.7" |
