Product description The Radial Engineering EXTC-500 Guitar Effects Studio Interface enables creatively inclined engineers to introduce guitar pedals into the signal chain. The EXTC Studio Interface takes a balanced signal, unbalances it and reduces the level so that it can properly interface with hi-Z guitar pedals. Once the signal is processed, this studio interface reverses the process by taking the unbalanced signal and reconverts it back to a +4 dB balanced line level signal for easy manipulation in the professional recording environment. This, for instance, lets you add wah to a kick drum, tube distortion to a vocal track, or maybe an old-school tape echo to an acoustic guitar. As pedals can be noisy, the EXTC Studio Interface is transformer isolated to eliminate hum and buzz caused by ground loops. A 180° polarity reverse ensures that the wet-dry mix is in phase. - General
- 100% discrete class-A signal path
- Transformer isolated to eliminate noise
- Separate send & receive level controls
- Front panel ¼" jacks for easy connection
- Applications
- Lets you fatten up a track using pedals
- Allows you to add guitar effects like overdrive to voice
- Lets you use effect pedals in new ways
- Creative tool to make your tracks stand out
- Isolated output to eliminate ground loops
- Wet-dry mix to adjust the balance
- Can also be used for reamping
- Full Enclosure
- 100% steel casing reduces magnetic interference from other nearby modules that may cause pollution
- Blend Control
- Adjusts the wet-dry mix between the original unprocessed signal and the EXTC's effects loop
- 180º Polarity
- Lets you reverse the polarity of the wet signal path and bring it into phase with the dry signal when they are being mixed together
- Omni Insert
- Turns the Omniport insert jack into a second send & receive path for additional processing
- Send & Receive
- For adjusting the send level to the pedals and return path level back into the EXTC to optimize the signal-to-noise ratio
- ¼" Send & Receive
- Allows you to separate send and receive ¼" jacks used to connect guitar pedals to the EXTC. Front panel mounted to make connections easy for use on the desktop
- Omniport
- TRS jack is set up as an insert to connect to a remote patch bay or effect device. This follows the tip-send, ring-receive convention. It is available when used with Radial Workhorse racks.
- Gold 15-Pin Card Edge
- Double-sided and gold-plated edge connector ensures enhanced conductivity and signal transfer
- Transformer Isolation
- Helps eliminate hum and buzz caused by ground loops
- Class-A EFX Loop
- Radial's FET amplifier delivers natural tone and optimal signal transfer for high-impedance instruments and effects
