Product description The Key-Largo Keyboard Mixer and Performance Pedal from Radial Engineering is a device that combines a multichannel keyboard mixer with the performance attributes of real-time footswitch control. Featuring three dual 1/4" analog inputs for keyboards, and a USB interface to connect a laptop for use with soft-synths, the mixer can be used for stage and studio applications.Each stereo input on the mixer is equipped with individual level control for quick adjustments, along with an effects loop to interface an external multi-effects device. It is built with a footswitch to activate the echo or reverb effect when desired. In addition, a built-in sustain footswitch lets you connect the Key-Largo to your master keyboard or digital piano using a standard guitar cable, which eliminates the need to bring a separate sustain footswitch to the gig.Furthermore, the Key-Largo is made of solid 14-gauge steel construction, with steel-shafted potentiometers and switches to handle the abuse of being on the road. The main outputs provide a balanced connection to the PA system and are transformer-isolated to eliminate hum and buzz.Finally, with both USB and MIDI connectivity, the Key-Largo easily integrates with all types of keyboard setups. The 24-bit/192 kHz converters allow playback of the best sample libraries and soft-synths, and provide the ability to record over USB with professional-quality audio. - Manage a Multi-Keyboard Setup with Ease
- The Key-Largo effortlessly mixes multiple keyboard outputs down to a stereo feed for the PA system over XLRs. Add more excitement to the performance with a switchable effects loop and a master volume pedal.
- Integrate a Soft-Synth on Stage
- The Key-Largo allows you to take the MIDI output from a controller to play a soft-synth on your laptop. The high-quality digital-to-analog converters give you great sound quality on local monitors and at the PA system.
- Combine Analog and Digital on Stage
- Mix three keyboards together with the output of a laptop soft-synth, which makes the Key-Largo the center of your performance setup. Connect a 1/4" cable to the footswitch input on your main keyboard to utilize the Key-Largo as a sustain pedal.
UPC: 676101044320 In the Box Radial Engineering Key-Largo Keyboard Mixer and Performance Pedal 15 VDC Adapter Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Radial Engineering Key-Largo Keyboard Mixer and Performance Pedal in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRadial Engineering R800 1427 Specs | Audio Circuit Type | Active circuit with audio-grade operational amplifiers | | Frequency Response | 20 Hz to 20 kHz, ±0.5 dB | | Noise Floor | -91 dB | | Input Clip Level | +12 dBu | | Output Clip Level | +24 dBu | | Total Harmonic Distortion (THD) | <0.005% @ 1 kHz | | Input Impedance | Analog: 20 kOhms
FX Return: 50 kOhms
Volume Return: 485 kOhms | | Output Impedance | XLR: 300 Ohms
FX Send: 1 kOhm
Volume Send: 300 Ohms | | | | Power | 260 mAh, 15 VDC (center pin positive) | | Material of Construction | 14-gauge steel | | FCC Compliance | Complies with section 15 of the FCC rules | | Operating Conditions | For indoor use | | Operating Temperature | 41 to 104°F (5 to 40°C) | | | | Package Weight | 4.425 lb | | Box Dimensions (LxWxH) | 13.35 x 5.5 x 3.3" |
