Product description Eliminating hum and buzz caused by ground loops for a variety of audio signal types, the StageBug SB-6 Isolator from Radial Engineering is a 2-channel device that features 1/4" inputs and outputs for both Hi and Lo-Z signals, with the ability to convert one to the other depending on the connectors in use. Its dual linear Eclipse transformers are designed to provide flat response from 20 Hz to 20 kHz, and provides you with a phase reverse switch for phase alignment of stereo signals as well as a -15dB pad. - Isolator for balanced and unbalanced signals
- Eliminates hum and buzz caused by ground loops
- Exceptionally linear from 20 Hz to 20 kHz
- Automatically configures for Hi-Z or Lo-Z signal chains
UPC: 676101040681 In the Box Radial Engineering StageBug SB-6 Isolator Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Radial Engineering StageBug SB-6 Isolator in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRadial Engineering R800 0160 Specs | Audio Circuit Type | Passive transformers | | Frequency Response | 20 Hz to 20 kHz +/-1 db | | Dynamic Range | >140 dB | | Maximum Input | >+25 dBu | | Gain | -2 dB | | Total Harmonic Distortion | <0.0008% @ 1 kHz | | Phase Deviation | >5° @ 30 Hz | | Input Impedance | Varies with load 47 KΩ | | Output Impedance | 600 Ω | | Features | Transformer: Eclipse custom
Input Pad: -15 dB
Polarity: 180° reverse
Ground Lift: Disconnects TRS sleeve at output | | Input Connector | 1/4" (6.3 mm) TRS phone | | Output Connector | 1/4" (6.3 mm) TRS phone | | Construction | 14 gauge steel chassis & outer shell | | Power | Passive, no power required | | Operating Conditions | For use in dry locations only between 41 to 104°F (5 to 40°) | | Dimensions (L x W x D) | 4.50 x 1.85 x 1.35" (114 x 47 x 34 mm) | | Weight | 0.9 lb (408 g) | | | | Package Weight | 1.0 lb | | Box Dimensions (LxWxH) | 7.3 x 4.7 x 2.1" |
