Product description Women of Influence: Katrin Eismann Read More Access, view and analyze the pure raw data as recorded by your DSLR and certain video cameras with RawDigger's Exposure Edition from LibRaw LLC. RawDigger is not a raw converter; it is a microscope of sorts that lets you drill down into your image files and visualize the data that will be used by raw converters. With this software, the isolation layer normally imposed by raw converters becomes transparent.
The Exposure edition is intended for everyday use, to help practitioners who are serious about extracting the maximum quality from their camera by delivering precise exposures. RawDigger allows you to display and research data from the real raw histogram, which greatly differs from the in-camera histogram, as well as histograms presented by most raw converters.
To facilitate accurate raw image study, the histogram for either the entire file or an isolated image segment can be viewed in all modes (RGB, raw composite, and raw per channel). It can also be exported for further study as a spreadsheet (CSV) or a graphic file (PNG) for presentation.
RawDigger can help you determine the calibration of an in-camera exposure meter and quantify different vignetting sources. It also helps you to use spot-metering, exposure compensation, and manual exposure settings more efficiently and reliably.
The software allows you to monitor and improve studio lighting setups in terms of white balance/light uniformity, and dynamic range. Additionally, indicators for over- and underexposed image areas show you exactly where and in which color channel(s) details are blown out or have noisy shadows, with statistics to indicate the percentage of over- or underexposed pixels.
RawDigger supports all raw formats (including DNG) associated with a list of more than 800 supported cameras, and frequent updates are made to support new DSLR and cell phone models. The software can read files from any media, from a flash card to a network server. It works on a variety 32/64-bit Windows, Intel-based Mac platforms and Linux Wine-1.2.3; Wine (1.3.37-0ubuntu1~ppa1~lucid1) and Debian testing.
This version of RawDigger is delivered as a download, and the license key can be installed on up to two computers simultaneously. - Analyze Camera Behavior and Settings
-
- Determine how the camera's exposure meter is calibrated
- Identify the camera's dynamic range
- Establish the raw level corresponding to the midpoint of in-camera histogram
- Check which camera settings affect raw data
- Analyze ISO settings to determine ideal tolerances
- Evaluate the accuracy, repeatability, and uniformity of a range of shutter speeds
- Determine the actual T-stop of a lens
- Compare noise between two cameras of the same make and model
- Tune a new camera to apply customary exposure metering and setting techniques
- Determine the idiosyncrasies of both camera and raw converter by comparing raw data to results obtained through raw conversion
- Display and Research the Real Raw Histogram
-
- Compare raw histogram to in-camera histogram and account for differences, so to expose files as much to the right as possible (ETTR)
- Display histograms in different modes: RGB render, composite raw and per-channel raw (R, G, and B or R, G1, B, G2 - for Bayer-type sensors) views
- Display histogram of entire image or a rectangular selection of image portions
- Export histograms for further study as a spreadsheet (CSV), or as a PNG for presentation
- Verification of Lighting Conditions
-
- Identify proper light filtration for cleanest possible image shadows
- Check neutrality of polarizing/neutral density filters and identify proper color correction/compensation filters for various light sources
- Establish headroom in highlights to obtain optimal exposures
- Investigate Conditions for Noise in Shadows
-
- Investigate exposure conditions and camera settings that cause unacceptable noise levels in shadows
- Estimate the level of noise introduced by the raw converter, compared to natural noise from the camera sensor
- Examine relative per-channel underexposure based on the color of light (correlated color temperature, CCT, and tint, or neutralizing white balance coefficients)
- Determine degree of underexposure in shadows and set software's Underexposure (UE) indicator to suit your needs
Compatibility - Canon
- PowerShot 600/A5/5 Zoom/50; Pro1/70/90 IS; G1/1X/1X Mark II/2/3/3X/5/6/7X/9/10/11/12/15/16; S30/40/45/50/60/70/90/95/100/110/120; SX1 IS/50 HS/60 HS; PowerShot (CHDK hack) A460/470/530/550/570/590/610/620/630/640/650/710 IS/720 IS/3300 IS; G7; S2 IS/3 IS/5 IS; SD300/950; SX110 IS/120 IS/220 HS/20 IS/30 IS; EOS D30/60; 5D/DS/DS R/Mark II/ III, 6D, 7D/Mark II, 10D, 20D/Da, 30D, 40D, 50D, 60D/Da, 70D, 1200D, C500, D2000C; M/2/3; 1D/DS/D C/D X/Mark II/Mark II N/Mark III/Mark IV; 1Ds Mark II/Mark III; EOS 300D/Digital Rebel (DR)/Kiss Digital (KD), 350D/DR XT/KD N, 400D/DR XTi/KD X, 450D/DR XSi/KD X2, 500D/DR T1i/KD X3, 550D/DR T2i /KD X4, 600D/DR T3i/KD X5, 650D/DR T4i/KD X6i, 700D/DR T5i, 750D/DR T6i, 760D/DR T6S, 100D/DR SL1, 1000D/DR XS/KD F, 1100D/DR T3/KD X50
- Nikon
- D1/1H/1X/2H/2Hs/2X/2Xs/3/3s/3X/4/4s/40/40X/50/60/70/70s/80/90/100/200/300/300s/600/610/700/750/800/800E/810/810A/3000/3100/3200/3300/5000/5100/5200/5300/5500/7000/7100/7200/Df; 1/AW1/J1/J2/J3/J4/J5; S1/S2; V1/V2/V3; E700/800/880/900/950/990/995/2100/2500/3200/3700/4300/4500 ("DIAG RAW" hack); E 5000/5400/5700/8400/8700/8800; COOLPIX A/P330/340/6000/7000/7100/7700/7800; S6 ("DIAG RAW" hack); COOLSCAN NEF
- Olympus
- AIR A01; C 3030Z/5050Z/5060Z/7070WZ/70Z/7000Z/740UZ/770UZ/8080WZ; X200/D560Z/C350Z; E-1/3/5/10/20/30/300/330/400/410/420/450/500/510/520/600/620/P1/P2/P3/P5/PL1/PL1s/PL2/PL3/PL5/PL6/PL7/PM1/PM2/M1/M10/M5/M5 Mark II; SP310/320/350/500UZ/510UZ/550UZ/560UZ/565UZ/570UZ; STYLUS1/1s; SH-2; TG-4; XZ 1/2/10
- Panasonic
- AG-GH4; DMC-CM1/FZ8/FZ18/FZ28/FZ30/FZ35/FZ38/FZ40/FZ50/FZ7/FZ70/FZ100/FZ150/FZ200/FZ300/ 330/FZ1000/FX150/G1/G10/G2/G3/G5/G6/G7/G70/GF1/GF2/GF3/GF5/GF6/GF7/GH1/GH2/GH3/GH4/GM1/GM1s/GM5/GX1/GX7/GX8/L1/L10/LC1/LX1/LF1/LX2/LX3/LX5/LX7/LX100/TZ60/61/SZ40/TZ70/71/ZS50
- Sony
- A 7/7 II/7R/7R II/7S; ILCA-77M2 (A77-II); ILCE-3000/5000/5100/6000/QX1; DSC-F828/R1/RX1/RX1R/RX10/RX10II/RX100/RX100II/RX100III/RX100IV/V3; DSLR-A100/A200/A230/A290/A300/A330/A350/A380/A390/A450/A500/A550/A560/A580/A700/A850/A900; NEX-3/3N/5/5N/5R/5T/6/7/C3/F3/VG20/VG30/VG900; SLT-A33/A35/A37/A55V/A57/A58/A65V/A77V/A99V; XCD-SX910CR; IMX135-mipi 13mp/QCOM; IMX072-mipi
- Other Manufacturers
-
ARRIRAW format
AVT: F-080C/145C/201C/510C/810C
Adobe Digital Negative (DNG)
AgfaPhoto DC-833m
Alcatel 5035D
Apple: QuickTake 100/150/200
Baumer TXG14
BlackMagic: Cinema Camera/Pocket Cinema Camera/Production Camera 4k
Casio: QV 2000UX, 3000EX, 3500EX, 4000, 5700, R41/51/61; EX 10/100/100F; F1; FC300S/400S; FH20/25/100; S20/100; Z4/50/500/55/60/75/750/8/850/1050/1080; ZR100/700/710/750/800/850/1000/1100/1200/1300/1500/3000; Exlim Pro 505/600/700
Contax N Digital
Creative PC-CAM 600
DJI 4384x3288
Digital Bolex: D16/16M
Epson: R-D1/D1s/D1x
Foculus 531C
FujiFilm E: 505/900; F700/710/800/810/505EXR/550EXR/600EXR/605EXR/770EXR/775EXR/800EXR/900EXR; S: 2Pro/3Pro/5Pro/20Pro/1/100FS/5000/5100/5500/5200/5600/6000fd/7000/9000/9500/9100/9600/200EXR/205EXR/L1000; HS 10/11/20EXR/22EXR/30EXR/33EXR/35EXR/50EXR; X Pro1/S1/Q1/Q2/100/100S/100T/10/20/30/A1/A2/E1/E2/M1/F1/T1/T1 Graphite Silver/T10; IS-1
HTC UltraPixel
Hasselblad: H5D-60/50/50c/40; H4D-60/50/40/31; H3D II-22/31/39/50; H3D-22/31/39; H2D-22/39; CFV/H; CF-22/31/39; V96C; Lusso; Lunar; Stellar/Stellar II; HV
ISG 2020x1520
Ikonoskop: A-Cam dII/dII Panchromatic
Imacon: Ixpress 96/96C/132C; Ixpress 384/384C/528C (single shot only)
JaiPulnix: BB-500CL, BB-500GE
Kinefinity: KineMINI/RAW Mini/RAW S35
Kodak: DC20/25/40/50/120; DCS200/315C/330C/420/460/460A/460D/520C/560C/620C/620X/660C/660M/720X/760C/760M; DCS Pro 14n/14nx/SLR/c/SLR/n; EOSDCS1/3B; NC2000F; ProBack; PB 645C/H/M; C 330/603; P 850/880; S-1; Z 980/981/990/1015; KAI-0340
Konica: KD-400Z/510Z
Leaf: AFi 7; AFi-II 5/6/7/8/10/10R/12/12R; Aptus 17/22/54S/65/75/75S; Cantare, CatchLight, CMost; Credo: 40/50/60/80; DCB2; Valeo 6/11/17/22; Volare
Leica: C (Typ 112); Digilux 2/3; Digital-Modul-R; D-LUX 2/3/4/5/6/(Typ 109); M 8/8.2/9/(Typ 240); Monochrom (Typ 240)/(Typ 246); M-E/-P; R8; Q (Typ 116); S/S2; T (Typ 701); X1, X (Typ 113), X2, X-E (Typ 102); V-LUX1/2/3/4/(Typ 114); X VARIO (Typ 107)
Lenovo a820
Logitech Fotoman Pixtura
Mamiya ZD
Matrix 4608x3288
Micron 2010
Minolta: RD175; DiMAGE 5/7/7i/7Hi/A1/A2/A200/G400/G500/G530/G600/Z2; Alpha/Dynax/Maxxum 5D/7D
Motorola PIXL
Nokia: N95, X2, 1200x1600, Lumia 1020/1520
OmniVision OV5647 (Raspberry Pi)
Pentax: *ist D/DL/DL2/DS/DS2; GR; K10D/20D/100D/100D Super/110D/200D/2000/K-m; K-x/K-r/K-01/K-3/K-3 II (std mode)/K-30/K-5/K-5 II/K-5 IIs/K-50/K-500/K-7/K-S1/K-S2/MX-1; Q/Q7/Q10/QS-1; Optio S/S4/33WR/750Z/645D/645Z
PhaseOne: IQ140/160/180/250/260/260 Achromatic/280; LightPhase; Achromatic+; H 10/20/25; P 20/20+/21/25/25+/30/30+/40+/45/45+/65/65+
Photron BC2-HD
Pixelink A782
Polaroid x530
Ricoh: GR/GR Digital/Digital II/Digital III/Digital IV; GX100/200; GXR MOUNT A12/ A16 24-85mm F3.5-5.5; GXR, S10 24-72mm F2.5-4.4 VC/GR A12 50mm F2.5 MACRO/GR LENS A12 28mm F2.5/GXR P10
Rollei d530flex
RoverShot 3320af
SMaL Ultra-Pocket 3/4/5
STV680 VGA
SVS SVS625CL
Samsung: EX 1/2F; GX-1L/1S; GX10/20; Galaxy S3/Nexus/ NX (EK-GN120); NX1/5/10/11/100/1000/1100/20/200/210/2000/30/300/300M/3000/500/mini; Pro815; WB 550/2000; S85/S850 (hacked)
Sarnoff 4096x5440
Seitz: 6x17, Roundshot D3/D2X/D2Xs
Sigma: SD9/10/14/15/1/1 Merill; DP 1/1 Merill/1S/1X/2/2 Merill/2S/2X/3 Merill; dp0 Quattro/1 Quattro/2 Quattro/3 Quattro
Sinar: eMotion 22/54/75; eSpirit 65; eVolution 75; 3072x2048, 4080x4080, 4080x5440; STI format; Sinarback 54 Table of Contents
|
Upload User Manual
Have you got an user manual for the RawDigger Software, Exposure Edition in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRawDigger RD1EE Specs | Delivery | License key with activation code | | Mac System Requirements | System support for 32/64-bit Intel Mac running Mac OS X 10.5 or newer
Screen resolution of 1024x768 or higher | | Windows System Requirements | System support for Windows XP SP2+, Vista, 7, 8, 8.1, 10 (32/64-bit)
1 GB memory, CPU supporting SSE2 or higher (Intel Pentium 4 or newer)
Screen resolution of 1024x768 or higher | | Linux System Requirements | User reports indicate using Wine to run RawDigger under OS X and Linux Configurations tested are OS X 10.6.8 and Wine-1.2.3; Wine (1.3.37-0ubuntu1~ppa1~lucid1) and Debian testing. | | Image Display | Options for rgb render, composite raw and per-channel raw (R, G, and B or R, G1, B, G2 for Bayer-type sensors) | | Supported File Formats | Supports all raw formats (including DNG) from the following list: ARW, CR2, CRW, DC2, DCR, DNG, ERF, EIP, FFF, HDR, MOS, MRW, NEF, ORF, PEF, RAF, RAW, RDC, SR2, SRF, RMF, 3FR, CINE, IA, KC2, MEF, NRW, RW2, STI, IIQ, SRW, X3F, RWL, DRF, DSC, PTX, CAP, BAY, BMQ, PXN, CS1, K25, KDC, MDC, QTK, Kodak raw TIF |
