User Manual for Raytec RAYLUX 200 White-Light LED Illuminator with Adaptive Illumination Click to enlarge the picture
Contents of the user manual for the Raytec RAYLUX 200 White-Light LED Illuminator
- Product category: Illuminators Raytec
- Brand: Raytec
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Raytec Illuminators
|
User manual for the Raytec RAYLUX 200 White-Light LED Illuminator contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Raytec product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Raytec user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Raytec product will considerably shorten its lifespan!
|
Product description The silver RAYLUX 200 White-Light LED Illuminator from Raytec is equipped with surface mount LEDs to provide even illumination and clear night-time images for surveillance cameras and general area lighting. The illuminator uses the Adaptive Illumination concept to alter the angle of illumination onsite to suit required lighting specifications. The RAYLUX 200 illuminator provides a white-light output of 110 lumens/W at the LED source and an independently tested luminaire output of 4700 lumens. The unit is fitted with Active LED Life Control to control LED output, delivering consistent illumination power and a projected working life of 10 years. The RAYLUX 200 illuminator comes with a bracket and a power supply. Control features on the power supply include adjustable power output, photocell, and telemetry control. The illuminator is designed for low-light installations up to 656'. - 120 to 180° coverage angle
- Fully controllable power supply
- IP66-rated weather-resistant and vandal-resistant enclosure
- Includes a power supply with an adjustable photocell, adjustable power output for IR, and telemetry control
- Used at prisons, water reservoirs, industrial parks, dome systems, and power plants
In the Box Raytec RAYLUX 200 White-Light LED Illuminator with Adaptive Illumination (120 to 180°, Silver) U Bracket Adaptive Illumination Bracket Standard Power Supply Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Raytec RAYLUX 200 White-Light LED Illuminator with Adaptive Illumination in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRaytec RAYLUX 200 Specs | | | Lumens | Source: 110 lumens/W
Luminaire: 80 lumens/W
Total Lumens: 4700 per luminaire | | Maximum Distance | Narrow Angle: Up to 98' / 30 m
Wide Angle: Up to 69' / 21 m | | Angle | 120 to 180° | | Optics | SMT LEDs | | Consumption | 80 W maximum | | Voltage | 14 V current controlled | | Color Temperature | 6500K | | CRI | 74 to 80+ | | Environmental | IP66 | | Temperature Range | -58 to 122°F / -50 to +50˚C | | Cable Length | 8.2' / 2.5 m | | Wavelength | White light | | Dimensions | 11 x 8 x 3" / 280 x 195 x 66 mm | | Weight | 8.8 lb / 4 kg | | | | Input | Universal 100 to 230 VAC auto-sensing | | Output | Maximum 80 W | | Temperature | -58 to 122°F / -50 to 50°C | | Dimensions | 6 x 6 x 4" / 160 x 160 x 90 mm | | Weight | 4 lb / 1.8 kg |
