User Manual for Raytec RAYMAX 300 Series Panoramic Illuminator Click to enlarge the picture
Contents of the user manual for the Raytec RAYMAX 300 Series Panoramic Illuminator
- Product category: Illuminators Raytec
- Brand: Raytec
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Raytec Illuminators
 |
User manual for the Raytec RAYMAX 300 Series Panoramic Illuminator contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Raytec product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Raytec user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Raytec product will considerably shorten its lifespan!
|
Product description The black RAYMAX 300 Series Panoramic Illuminator from Raytec features a much better spread of light and longer illumination distances, making it suitable for wide angle, PTZ, or 360° dome cameras, which cover large areas. It utilizes holographic lens technology to spread and control the light, creating a softer and more even distribution. It also features Hot-Spot Reduction Technology (HRT), directing the light where it is most needed to not only deliver longer illumination distances and minimize light waste, but also to provide full scene coverage without hot spots caused by overexposure.The illuminator is designed to offer a working life of 10 years and zero maintenance. The adaptive Illumination allows installers to adjust the 60 to 180° angle of light projection according to specific security needs and a camera's field of view. It includes Active LED Life Control that controls LED output during the illuminator's life cycle. It also incorporates the surface mount LED technology to deliver remarkable performance. The illuminator includes a power supply with an adjustable power output, an adjustable photocell, and telemetry control. In the Box Raytec RAYMAX 300 Series Panoramic Illuminator (60 to 180° x 25°, Black) Standard Power Supply U Bracket Adaptive Illumination Bracket Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Raytec RAYMAX 300 Series Panoramic Illuminator in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRaytec RAYMAX 300 Specs | | | Max Distance | 525' / 160 m | | Angle | 60 to 180 x 25° | | Wavelength | 850 nm | | Optics | SMT LEDs | | Voltage | 14 V current controlled | | IP Rating | IP66 | | Temperature Range | -58 to 122°F / -50 to 50°C | | Power Consumption | 165 W | | Cable Length | 8.2' / 2.5 m | | Dimensions | 16 x 8 x 3" / 41 x 20 x 8 cm | | Weight | 13.2 lb / 6 kg | | | | Input | Universal 100 to 240 VAC auto-sensing | | Output | 165 W maximum | | Temperature | -58 to 122°F / -50 to 50°C | | IP Rating | IP66 | | Dimensions | 9 x 6 x 3" / 23 x 15 x 8 cm | | Weight | 5.3 lb / 2.4 kg |
Rating90% users recommend this product to others. And what about you?
This product has already been rated by 93 owners. Add your rating and experience with the product.
