User Manual for RDL FP-MPA2 - Dual Channel Phantom Power Adapter Click to enlarge the picture
Contents of the user manual for the RDL FP-MPA2 - Dual Channel Phantom
- Product category: Phantom Power Supplies RDL
- Brand: RDL
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for RDL Phantom Power Supplies
|
User manual for the RDL FP-MPA2 - Dual Channel Phantom contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any RDL product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official RDL user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a RDL product will considerably shorten its lifespan!
|
Product description The FP-MPA2 from RDL is the ideal choice in any applications where phantom power needs to be provided to powered microphones. Two identical circuits are provided, with connections through XLR jacks. The microphone is connected to the module through the female XLR jack. The selected phantom voltage is applied to this jack. The microphone signal output is available on a male XLR. Phantom is blocked from this output jack. The phantom voltage is individually selectable for each input. A three position switch is provided for choosing 12V, 24V or 48V. Some microphones operating on 24V phantom perform optimally with higher value buildout resistances. For these particular powered microphones, a second switch is provided to select the optimum current. The appropriate voltages are generated through a low-noise dc-dc converter and regulator circuits. Each phantom output is short-circuit protected. The FP-MPA2's low profile and compact size permit mounting in confined spaces and in various locations in equipment racks. The location of the input/output jacks permits high-density mounting against flat surfaces while maintaining accessibility to the connectors. - Compact, phantom power adapter for two microphones
- Switchable phantom voltage (12V, 24V and 48V)
- Selectable current for 24V microphones
- All standard buildout resistances
- Ultra-compact all metal construction
- Cabinet, shelf or rack mounting
UPC: 813721012487 In the Box RDL FP-MPA2 - Dual Channel Phantom Power Adapter Three (3) Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the RDL FP-MPA2 - Dual Channel Phantom Power Adapter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRDL FP-MPA2 Specs | Number of Channels | 2 | | Inputs | 2 x XLR | | Output | 2 x XLR | | Phantom Power | 12V, 24V or 48V | | Multi Function | No | | Gain Range | Not applicable | | Maximum Output Level | Not applicable | | Frequency Response | Not applicable | | Noise | Not applicable | | Dimensions (WxDxH) | 4 7/8" x 3 1/4" x 1 3/8" | | Weight | Not specified by manufacturer | | Specialties | Requires ground-referenced, 24Vdc @ 100mA power source | | | | Package Weight | 1.12 lb | | Box Dimensions (LxWxH) | 7.0 x 4.0 x 2.0" |
