Product description The Redrock Micro Atlas Smart Motor Upgrade Bundle for microRemote includes an Atlas Smart Motor and a D-Tap power cable. This is assembled to provide you with a motor that can be used on almost any camera/lens combination as long as the lens features a 0.8 MOD lens gear and you have a D-Tap power source. The motor features a bushing that enables using it on either a 15 or 19mm support rod.
This bundle has been assembled to meet the needs of cine-style production where accessory power is usually available via a D-Tap. The motor is small and lightweight, yet powerful with more torque and resolution than previous motors from Redrock Micro. A host of advanced features are packed into this motor, which is configurable wirelessly from the Eclipse app. - Atlas Smart Motor (Single Motor Standalone) The Redrock Micro Atlas Smart Motor features a compact design with increased torque and resolution compared to Redrock's previous motors. This is the standalone configuration of the motor which includes a single motor with a removable 0.8 MOD drive gear. The included 15 to 19mm bushing allows you to mount the motor on either cine-rod standard. The motor features both manual and automatic calibration. Though small in size, it has many advanced features including rotating ports that make cabling easier, LED indicators, and an OLED display screen.
Well suited to either focus, iris, or zoom, the motors are hardwired and can be daisy-chained as each one can function without a separate control box or MDR, greatly saving you on weight. The motors also support Wi-Fi, RF, NFC, and S.Bus control for a truly flexible system. The free Eclipse mobile app makes setup and calibration a breeze. -
- Works with virtually any camera and lens
- Removable 0.8 MOD drive gear
- Wireless-ready (2.4 GHz)
- No external brain/MDR/control/distribution box required
- Auto and manual calibration
- One-button push for auto calibration
- Adjustable torque
- Onboard LED and OLED for visual confirmation of status and configuration
- Rotating ports simplify cabling and rigging
- Hemo-style connectors eliminate cable mismatch
- Wide selection of add-on controllers—solo op fingerwheel, mini FIZ, wireless remote, drone
- Included Eclipse mobile app for configuration and wireless remote focus control
- Mission Control-ready—display real-time focus information on compatible smallHD monitors (not included)
- MetaTouch offers lens discovery and configuration for fast lens changes just by touching the lens
- Eclipse to D-Tap Power Input Cable (24") This Redrock Micro Eclipse to D-Tap Power Input Cable is 24" long and connects your Eclipse module to a D-Tap power source. The 4-pin push/pull connector ends create a strong and durable connection to your module, while the D-Tap connector end is standard for powering accessories requiring 12 to 14.8 VDC. The braided cable sheath protects the wires inside.
In the Box Bundle Items Atlas Smart Motor (Single Motor Standalone) Eclipse to D-Tap Power Input Cable (24") Table of Contents
|
Upload User Manual
Have you got an user manual for the Redrock Micro Atlas Smart Motor Upgrade Bundle for microRemote in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Atlas Smart Motor (Single Motor Standalone)
| Material of Construction | Aircraft-Grade Aluminum | | Connector | Connector 1: Eclipse Net Power and Communications
Connector 2: Eclipse Net Power and Communications
Connector 3: Mini Control Port S.Bus | | Wi-Fi Compatibility | Frequency: 2.4 GHz
NFC: Yes | | Power | 12 to 18 VDC | | Dimensions | 3.78 x 1.14 x 2.8" / 9.6 x 2.9 x 7.1 cm | | Weight | 8.4 oz / 238 g | - Eclipse to D-Tap Power Input Cable (24")
| Connectors | 4-pin Hemo push/pull
D-Tap | | Length | 24" / 61 cm | | Weight | 4 oz / 113.4 g | | | | Box Dimensions (LxWxH) | 5.0 x 1.0 x 0.5" |
