Product description This kit from Redrock Micro includes one 18" long 7-Pin LEMO to 7-Pin LEMO flexCable for microRemote Torque Motor and one 12" long D-Tap to 2-Pin LEMO flexCable for microRemote. This flexCable upgrade kit includes everything you need to optimize your microRemote wireless focus system with DJI Ronin gimbals. It replaces the microRemote standard cable with an ultra-flexible, lightweight flexCable with lengths and connectors optimized for the Ronin. - D-Tap to 2-Pin LEMO flexCable for microRemote (12") This 12" long Redrock Micro D-Tap to 2-Pin LEMO flexCable for microRemote is for powering an optional microRemote from a D-Tap power source. The 12" cable is designed for use specifically with gimbals where the D-tap battery port is closer to the microRemote Basestation, such as the DJI Ronin's D-tap battery ports, which are located on the camera sled.
Designed to be 200% more flexible than standard cables, which means easier cable wrangling and less drag when using accessories between the camera and gimbal frame, such as when using a Fingerwheel controller or for power connections. - The D-Tap connector is also known as a P-Tap connector.
- 7-Pin LEMO to 7-Pin LEMO flexCable for microRemote Torque Motor (18") This 18" long Redrock Micro 7-Pin LEMO to 7-Pin LEMO flexCable for microRemote Torque Motor connects to the 7-pin connector on an optional microRemote Basestation to an optional microRemote Torque motor, delivering both power and control from the basestation to the motor.
Designed to be 200% more flexible than standard cables, which means easier cable wrangling and less drag when using accessories between the camera and gimbal frame, such as when using a Fingerwheel controller or for power connections. In the Box Bundle Items D-Tap to 2-Pin LEMO flexCable for microRemote (12") tdzcxtdtuuubvrsvttdqsyzubsccud 7-Pin LEMO to 7-Pin LEMO flexCable for microRemote Torque Motor (18") Table of Contents
|
Upload User Manual
Have you got an user manual for the Redrock Micro DJI Ronin - microRemote flexCable Wireless Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - D-Tap to 2-Pin LEMO flexCable for microRemote (12")
| Length | 12" / 30.5 cm | | Connector 1 | D-Tap | | Connector 2 | 2-pin LEMO | | Weight | 2 oz / 57 g | | | | Box Dimensions (LxWxH) | 4.4 x 2.2 x 0.3" | - 7-Pin LEMO to 7-Pin LEMO flexCable for microRemote Torque Motor (18")
| Length | 18" / 46 cm | | Connector 1 | 7-pin LEMO | | Connector 2 | 7-pin LEMO | | Weight | 2 oz / 57 g | | | | Box Dimensions (LxWxH) | 4.9 x 1.6 x 1.1" |
