Product description The Revolabs Fusion 8-Channel Wireless Conferencing System is a complete wireless audio solution for mid- to- large -size conference rooms where installed audio equipment is not available. The Fusion combines the wireless receiver for the microphones with a digital signal processor, audio mixer, and Acoustic Echo Cancellation and Noise education technology. The wireless system provides all the connectors required for connectivity between speakers or amplifiers in the room. It can also be directly connected to most major video conferencing solutions in the field, such as Lifesize, Polycom, Sony and Tandberg, making it the suitable for unified communication for conference rooms. To enable telephone conferences, the Fusion includes a telephone line-in connector that plugs in directly to a telephone network as a conference phone. It also provides a telephone set connection, allowing users to plug a desktop phone in for non-speaker calls. The wireless dialer enables users to set up calls from anywhere in the conference room. The microphones (sold separately) are sleek in design and come in several different styles such as wearable, tabletop directional, tabletop omni-directional, and XLR adapter for handheld and broadcast quality microphones. Also, the microphones used with the Fusion system can be mixed and matched based on the needs of the conference room. All wireless communication between the microphones and the Fusion is digitally encrypted using 128-bit encryption technology, securing the communication and preventing unwanted listeners from listening in. Rechargeable batteries in the microphones provide up to eight hours of talk time with a two-hour recharge time. With this wireless solution, Enterprise users can finally move around their conference room, and still be heard. The system comes with a 3-year silver service plan. Note: Microphones are sold separately. - Wideband frequency response provides high definition audio delivering spoken word clarity
- Wireless functionality lets users sit anywhere within a conference room or walk around freely
- Multiple microphone support including wearable, tabletop boundary and handheld 1
Please Note: Microphones are sold separately. close - RF Armor technology lets microphones operate "buzz" free, even when in direct contact with other wireless electronic devices
- 128-bit encryption prevents unwanted listeners
- 3-year silver service plan
In the Box Revolabs Fusion 8-Channel Wireless Conferencing System with 3-Year Silver Service Plan Power Supply 3-Year Silver Service Plan Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Revolabs Fusion 8-Channel Wireless Conferencing System with 3-Year Silver Service Plan in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRevolabs 018FUSIONNM3Y Specs | | | Channels | 8 channels | | Radio Frequency | 1920 to 1930 MHz | | Range | 100.00' (30.48 m) without obstruction
Out-of-range alarm | | Bandwidth | 100 to 6,800 Hz | | | | Power | 24 VDC, 2.5 A locking power connector | | Power Supply | 100 to 240 V, 50 to 60 Hz | | Connectors/Interfaces | IR Remote Serial DB9 Sensor
Audio Control RJ-45 - firmware updates only
Telephone Line/Telephone Set-In RJ-11
Network RJ-45 - firmware updates only
Mic Level XLR male conference out
Aux In/ Aux Out line level RCA Plug
Record Out/Room Out line level RCA Plug
Conference In/ Conference Out line level RCA Plug | | Microphone | Supported
01-EXEMICEX-BLK-11, 05-TBLMICEX-OM-11, 05-TBLMICEX-DR-11, 06-XLRMIC-BLK-11 Sold separately. | | | | Connectors | 8 proprietary 4-pin microphone charge jacks | | Power Requirements | Base: 24 VDC, 2.5 A locking power connector | | Power Supply | 100 to 240 V, 50 to 60 Hz | | Charger | 5 VDC, 2 A, 100 to 240 V, 50 to 60 Hz | | | | Operating Temperature | 104 to 212°F (40 to 100°C) | | Humidity | 20 to 85 % | | | | Dimensions (W x H x D) | Base: 16.45 x 3.42 x 8.46" (41.80 x 8.70 x 21.50 cm)
Charger: 8.30 x 1.00 x 4.30" (21.1 x 2.55 x 10.90 cm) | | Weight | Base: 7.80 lb (3.53 kg)
Charger: 1.10 lb (0.49 kg) |
