Product description The RigWheels RigPlate Suction Mount consists of a RigPlate camera mounting plate and four C-Cup suction cups. Together they form a sturdy camera mounting platform to attach to a car, boat, or any moving vehicle or flat surface.
The cheese-style RigPlate offers numerous mounting points to attach a camera and accessories. It features fourteen 1/4"-20 and four 3/8"-16 threaded holes, as well as four 5/16" and five 3/8" pass-through holes.
The four 4.5" C-Cups provide a strong platform-mounting base. Each C-Cup features a vacuum pump mechanism and a stud that screws into the RigPlate. A red line on each cup's vacuum indicates when suction pressure on the cup is low.
The Suction Mount also includes one 3/8"-16 bolt and one 3/8" washer for mounting. Note: Disclaimer: This product should always be used with a secondary form of mounting. You should never leave a RigWheels suction mount unattended while in operation as there is always a chance that it may unexpectedly come loose and cause damage to your and/or others' property. RigWheels LLC is not liable for any damages arising from or caused by the use of this product. - RP01 RigPlate The RigWheels RP01 RigPlate serves as a resourceful component of the camera mounting hardware. Its first function is to serve as a mounting plate for attaching RigWheels. The RigPlate and 1 set of RigWheels (sold separately) provide with smooth movement as a tabletop / skater dolly that can be used on any smooth or hard surface.
Using the RigPlate as a pipe dolly gives a scalable slider / dolly option for the new generation of mid-size and compact cameras. Attaching 2 RigPlates together creates a captive-rail camera carriage that allows secure camera movement at any angle. Using the RigPlate in conjunction with RigAxels (sold separately) adds even more capability to this simple system with a more traditional tabletop dolly setup and a robust pipe-dolly option.
The RigPlate is a camera support platform and can be used for much more than camera movement. A variety of several different mounting points allow you to attach a myriad of accessories. There are ten 1/4-20 and five 3/8-16 threaded holes (industry standard sizes) in addition to four 5/16" and five 3/8" pass-through holes.
The RigPlate can be turned into a rock-solid suction mount by adding the A-Cups or B- Cups (sold separately). UPC: 854821004033 - C-Cup Suction Cup The RigWheels C-Cup Suction Cup is an industrial-grade suction mount used in creating camera vehicle rigs. The C-Cup features a vacuum pump mechanism and a stud that screws into the separately available RigPlate or RigAxel components.The C-Cup is one of the larger suction cup sizes offered by RigWheels, providing a strong platform-mounting base. A red line on the cup's vacuum mechanism provides a quick visual indicator of when pressure on the cup is low. Note: Disclaimer: This product should always be used with a secondary form of mounting. You should never leave a RigWheels suction mount unattended while in operation as there is always a chance that it may unexpectedly come loose and cause damage to your and/or others' property. RigWheels LLC is not liable for any damages arising from or caused by the use of this product.
- Features
-
- Industrial-grade camera rigging suction mount
- A red line indicates when the cup's pressure is low
- Screws directly into the separately available RigPlate or RigAxel components
- The heavy-duty C-Cup is one of several sizes offered by RigWheels
UPC: 856601008118 In the Box Bundle Items RP01 RigPlate aswwbfrratawdurdecwscqwwscyctucbva 4 x C-Cup Suction Cup
Also Includes - 3/8"-16 Bolt (0.75" Long)
- 3/8" Washer
- Limited 1-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the RigWheels RigPlate Suction Mount with 4.5" C-Cups in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - RP01 RigPlate
| | | Box Dimensions (LxWxH) | 12.2 x 8.5 x 0.4" | - C-Cup Suction Cup
| Dimensions and Weight | Not specified by manufacturer | | | | Box Dimensions (LxWxH) | 12.25 x 8.4 x 2.9" |
