Rode NTK Valve Microphone Voiceover and

User Manual for Rode NTK Valve Microphone Voiceover and Sound Isolation Filter Kit

• Product category: Tube Microphones Rode
• Brand: Rode
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Rode Tube Microphones

Product description

• Rode NTK Valve 1.0" Condenser Microphone
  • Mic Shootout 2: Affordable Large Diaphragm Condensers
  The Rode NTK Valve 1.0" Condenser Microphone is a large-diaphragm condenser microphone which employs Class-A valve circuitry resulting in a warm sonic character. Sporting a cardioid polar pattern, the NTK is designed for vocal and general instrument recording, while providing the sonic character found in higher-priced tube microphones. The capsule features a mylar dual diaphragm sputtered in gold to provide transparent signal reproduction and wide frequency response.The hand-selected and graded 6922 twin-triode valve comprises the core of the NTK's circuitry, providing an analog "warmth" and presence that meets the standards of the most demanding engineers. The microphone features a custom-built, Mu-metal transformer developed by Jensen Transformers. The end result is quiet, noise-free output at high-gain levels. The NTK features a separate power supply, providing +48V phantom power.
  Tube Circuitry
  • The Rode NTK features the 6922 twin-triode valve at the heart of its circuitry. The result is a warm sonic character similar to that found in higher-priced tube microphones.
  Quality Transformer Design
  • The custom-designed, Jensen Mu-metal transformer provides a low-noise, high-gain signal path on output.
  Separate Power Supply
  • A separate power supply provides +48V of phantom power.
  UPC: 698813000050
• Rode SMR Advanced Shock Mount for Large Diaphragm Condenser Mics
  • Mic Shootout 2: Affordable Large Diaphragm Condensers
  The Rode SMR is a professional-grade shock mount for large diaphragm condenser mics. Featuring a double-Lyre suspension system, the SMR enhances Rycote’s Lyre system by using a smaller inner Lyre to act as a tensioning element. The SMR's removable all-metal pop filter provides an integrated solution for plosive protection, that is washable and designed to last as long as the shock mount and microphone. The SMR's clamping system design utilizes a large surface area, allowing for ample friction and weight handling, without the need for over-tightening of the locking thread. With the load distributed over a greater surface area, the clamping system is designed to better withstand the wear and tear of repeated use.The SMR's frame is made from an engineering grade reinforced polymer. Vibration force is evenly distributed around the outer frame via the wide mounting rails, increasing the effectiveness of the Lyre system. A base nut is also included, suitable for all compatible Rode microphones. UPC: 698813003068
• Auray RF-C20 Studio Isolation Filter (Red Composite, Metal Back)
  • Mic Shootout 2: Affordable Large Diaphragm Condensers
  The red composite, metal back RF-C20 Studio Isolation Filter from Auray provides a solution for music producers, broadcasters, and podcasters looking to help isolate a microphone and achieve better recordings in a space that is less than ideal for capturing audio. The Auray Studio Isolation Filter makes capturing clean, dry vocals or instrument recordings sound more natural with less sonic coloration.The RF-C20 fits on a medium- to heavy-duty microphone stand and uses a rugged aluminum mesh frame, four-layers of acoustic treatment, a vented metal back, plus a layer of acoustic composite fiber to absorb unwanted ambient noise and control acoustic reflections. In a nutshell, if your recording vocals, voiceovers, or podcasts in an untreated room with hard surfaces, the RF-C20 provides advanced microphone isolation for better-sounding results.
  Microphone Isolation
  • Recording, broadcasting, or podcasting in rooms with little-to-no acoustic treatment can wash-out vocal or instrument audio recordings with echo reflections. The Auray Studio Isolation Filter minimizes reflections of unwanted noise bouncing off hard surfaces and entering your microphone. Usually, expensive acoustic foam is required on studio walls to absorb reflections and get a "dry" sound. With this reflection filter, you can achieve similar results in your own room or workspace.
  Four-Layer Acoustic Treatment
  • Four layers of acoustic treatment help to isolate your vocal and instrument recordings. A thick layer of composite fiber surrounds your microphone and absorbs unwanted reflections, as well as additional noise coming in from the room. Two more layers of fabric and a perforated mesh layer help deaden and disperse sound waves, leaving your incoming audio clean and dry with little to no coloration.
  Adjustable Microphone Position
  • Getting the right position with your microphone to capture vocals or instruments is a crucial step when recording audio. The RF-C20 allows you to adjust the microphone position horizontally and vertically. Slide the microphone closer to the filter for that dry sound or slide the microphone away from the filter to add more of the room ambience. You can also adjust the microphone height to fit the person or instrument you're recording. You can even alter the angle of the filter and microphone with a simple twist of a knob.
  Mounting Options
  • The Auray Studio Isolation Filter can be mounted three ways. Use the clamps to attach the filter to medium- to heavy-duty boom and microphone stands. The clamps provide quick attachment and minimize setup time. An included 5/8- to 3/8" adapter allows you to seat the filter directly to the top of your mic stand. In addition, you can mount the isolation filter upside down to a mic boom arm for overhead recording.
  UPC: 847628013827
• Auray RFMS-580 Reflection Filter Tripod Mic Stand
  • Mic Shootout 2: Affordable Large Diaphragm Condensers
  The RFMS-580 Reflection Filter Tripod Mic Stand from Auray features heavy duty steel construction and is capable of providing sturdy support to your reflection filter and studio microphone at the same time. The tripod stand design features collapsible legs for convenient storage and a telescoping center column that can be adjusted to reach a maximum working height of 76", including a standard reflection filter.

  The stand also features non-slip feet for added traction on hard surfaces as well as a 5/8" threaded adapter for attaching a shockmount or mic clip.
  • Provides sturdy support to a microphone and a reflection filter at the same time
  • May also be used as a speaker stand (may require 3/8" thread adapter)
  UPC: 847628576827

• NTK Valve 1.0" Condenser Microphone usfweddfbrvddtrdyttfrrsefbdcvvbfyq
• RC-2 Hard Plastic Case
• M-2 Stand Mount
• NTR-C 30' (10 m) Multicore Cable
• NTK-P Power Supply
• PL100 Power Cable
• 3/8 - 5/8" Thread Adapter
• Limited 1-Year Warranty Extends to 10-Years upon Registration

• SMR Advanced Shock Mount for Large Diaphragm Condenser Mics

• Auray - RF-C20 Studio Isolation Filter (Red Composite, Metal Back)

• Auray - RFMS-580 Reflection Filter Tripod Mic Stand

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Rode NTK Valve 1.0" Condenser Microphone

  Sound Field	Mono
  Operating Principle	Pressure Gradient
  Transducer	Condenser
  Diaphragm	1.0" / 25.40 mm
  Tube	Yes
  Polar Pattern	Cardioid
  Frequency Range	20 Hz to 20 kHz
  Equivalent Noise Level	12 dB A-Weighted
  Maximum SPL	158 dB SPL
  THD	1%
  Impedance	200 Ohms
  Sensitivity	-38 dB at 1 kHz

  Output Connectors	1 x 3-Pin XLR
  Length	8.19" / 208 mm
  Diameter	2.17" / 55 mm
  Weight	26.81 oz / 760 g

  Box Dimensions (LxWxH)	25.9 x 13.2 x 5.4"

• Rode SMR Advanced Shock Mount for Large Diaphragm Condenser Mics

  Dimensions	5.0 x 9.0 x 8.3" (130 x 220 x 210 mm)
  Weight	9.2 oz (260 g)

  Box Dimensions (LxWxH)	10.158 x 7.795 x 4.803"

• Auray RF-C20 Studio Isolation Filter (Red Composite, Metal Back)

  Material of Construction	Composite Fiber, Aluminum
  Dimensions (H x W x D)	14.6 x 17.5 x 13.3" / 37.2 x 44.5 x 33.8 cm
  Weight	8.2 lb / 3.7 kg

  Box Dimensions (LxWxH)	19.5 x 17.0 x 13.0"

• Auray RFMS-580 Reflection Filter Tripod Mic Stand

  Thread Size	5/8"
  Folded Height	35.2" (89.4 cm)
  Adjustable Height Range	42 to 68" (106.7 to 172.7 cm)
  Weight	5.2 lb (2.36 kg)

  Box Dimensions (LxWxH)	35.75 x 5.0 x 4.25"
