Product description The HT-RX01 HDBaseT Receiver from Roland receives an HDMI signal from an HT-RX01 receiver (sold separately) from up to 328 ft over a shielded CAT5e or higher Ethernet cable. This makes it possible to connect video cameras, Blu-ray decks, switchers, and other source equipment to LCD monitors, projectors, and other display devices. When used as a receiver for the HDBaseT output of an XS Series multi-format matrix switcher, RS-232C control signals can be extended along with video and audio signals. This can achieve audio/video transmission in school auditoriums, company conference halls, and other large spaces. - Receive HDMI signals to a compatible receiver from up to 328 ft over an Ethernet cable
- Re-convert HDBaseT signals to HDMI
- Up to 1080 / 60p and WUXGA support for HDMI
UPC: 761294507155 In the Box Roland HT-RX01 HDBaseT Receiver AC Adapter 3 x AC Plugs 6.5 ft (2 m) RS-232 Conversion Cable 3 x Ferrite Core Limited 1-Year Warranty on Parts Limited 90-Day Warranty on Labor Table of Contents
|
Upload User Manual
Have you got an user manual for the Roland HT-RX01 HDBaseT Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRoland HT-RX01 Specs | Input Formats | 480 / 59.94i, 576/50i, 480/59.94p, 576 / 50p , 720 / 59.94p, 720 / 50p, 1080 / 59.94i, 1080 / 50i, 1080 / 59.94p, 1080 / 50p, 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 1200, 1920 x 1200
RGB Formats: Conforms to VESA DMT version 1.0 revision 11
The maximum refresh rate of RGB is 75 Hz (excluding 1600 x 1200 and 1920 x 1200; the refresh rate of these 2 is 60 Hz)
1920 x 1200 / 60 Hz : Reduced blanking | | Audio Formats | Maximum: PCM 8 channels, Dolby Digital, True HD DTS-HD Master Audio | | Connectors | 1 x RJ45 input
1 x HDMI output
1 x 9 pin D-sub RS-232 | | Transmission Range | 328' (100 m) | | Operating Temperature Range | 32 to 104°F (0 to 40°C) | | Operating Humidity Range | 10 to 85 % (no condensation) | | Storage Temperature Range | -4 to 140°F (-20 to 60°C) | | Power Supply | AC Adapter | | Current Draw | 2 A | | Dimensions | 3.2 x 3.7 x 1.0" (8.1 x 9.3 x 2.4 cm) | | Weight | 0.7 lb (0.3 kg) | | | | Package Weight | 1.39 lb | | Box Dimensions (LxWxH) | 7.9 x 7.5 x 2.8" |
