Product description

• 3" Circle LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 3" Circle LitePad HO90 is suitable for a kicker or creating a circular highlight in your talent's eyes.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
• 3 x 6" LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 3 x 6" LitePad HO90 is suitable for fill lighting, and can be hidden inside a car to provide illumination where traditional lights can't fit.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
  UPC: 290903060120
• 3 x 12" LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 3 x 12" LitePad HO90 is suitable for fill lighting, and can be hidden inside a car to provide illumination where traditional lights can't fit.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
• 6 x 6" LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 6 x 6" LitePad HO90 is suitable for key or fill use, and the daylight balance allows it to blend in naturally in day exteriors or to approximate moonlight.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
• 6 x 12" LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 6 x 12" LitePad HO90 is suitable for key or fill use, and the daylight balance allows it to blend in naturally in day exteriors or to approximate moonlight.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
• 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight Rosco's 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight from Rosco is a versatile light system. The HO refers to high output, as this is noticeably brighter than the original LitePad, and 90 refers to the 90+ CRI rating. The HO90 features a color temperature of 5300K, and extremely soft glow without the multiple shadows common when using LED array lights. The unit stays cool to the touch, with only the edge becoming slightly warm.

  The fixture itself is less than 0.4" thick, and it is built using an edge-lit piece of acrylic. The LEDs arranged around the edge illuminate channels that diffuse the light providing an extremely soft source that is easy on your talent's eyes and is suitable for key or fill based on the size of your LitePad. You can adjust the brightness using optional dimmers. The power connector is incorporated into the fixture itself and is not hard wired as with the original.
  LitePad HO90
  • The edge-lit design of the LitePad provides for an extremely soft glowing source, which was pioneered by Rosco for use in the film industry.
  Uses
  • The 12 x 12" LitePad HO90 is suitable for key or fill use, and the daylight balance allows it to blend in naturally in day exteriors or to approximate moonlight.
  Rugged Housing
  • The rigid plastic construction of the HO90 LitePad makes for a durable yet lightweight fixture.
  Interior Connector
  • LitePad's new interior connector eliminates the previous hardwire system, which had the potential to be pulled out during use causing damage to the fixture and requiring down time for repair. Based on user feedback, this feature was introduced to make the LitePad more rugged and easier to use.
  Low Heat
  • Because LitePad is an LED light source, the amount of heat generated is very low and does not require forced air cooling.
  Minimal Power Consumption
  • With each LED only consuming a quarter of a watt, LitePad is an extremely energy efficient light source. There is no longer the need for kilowatts of power or a generator to power a set full of lights. A few dozen LitePads can easily run off of available household power.
  Easy on the Eyes
  • Unlike many LED sources, LitePad is a bounced LED light - not an array of LEDs pointing directly forward. Performers or technicians can look directly into LitePad without squinting, hurting their eyes or getting a headache.
  Dimmable
  • LitePads are a fully dimmable LED product. The proprietary Single Fader Dimmer and 2 CH / DMX Dimmer can smoothly dim any standard size LitePad with no color temperature change. With LitePad's dimmers, you are able to set the exact light intensity you need.
• Car Adapter for LitePad This is a Rosco Car Adapter for the LitePad LED panels. Plug it into your auto's cigarette lighter or utility socket to provide the necessary 12VDC for your LitePad.
  Splitters Available
  • "Y" Splitter or a Four Way Splitter can be used to attach more than one LitePad (as long as the combined amperage of the LitePads does not exceed 4 amps).
• Y-Cable for LitePad The Rosco Y-Cable for LitePad™ fixtures allows connection of 2 fixtures to one power source.
• 10' Right Angle Extension Cable for LitePad The Rosco 10' Right Angle Extension Cable for LitePad adds an extra 10' (3 m) to the LitePad's transformer power supply. The right angle connector reduces the plug's profile and the possibility of crimping the cable.
• Four Way Splitter for LitePad The Rosco Four Way Splitter for the LitePad LED panel enables powering up to four LitePads with one single power source. The 3, or 5 amp power supply is suggested for use with this cable.
• XLR, Four Pin Adapter Cable for LitePad The Rosco XLR, 4 Pin Adapter Cable enables you to connect your XLR 12 volt DC battery source to any LitePad LED panel.
• Anton Bauer Adapter for LitePad The Rosco Anton Bauer Adapter enables operation of all LitePads with your 12 volt Anton Bauer Battery.
• Mounting Bracket for 3.0" LitePad The Rosco Mounting Bracket for 3.0" LitePad LED fixture allows the 3 x 6" or 3 x 12" Litepad to be mounted to any accessory that has a 1/4"-20 male screw, such as light stands, tripod heads or articulating arms.
  • Lightweight plastic
• Mounting Bracket for 6" LitePad The Rosco Mounting Bracket for 6" LitePad™ LED fixture enables aiming and positioning of the panel.
  • Lightweight plastic
• Mounting Bracket for 12" LitePad The Rosco Mounting Bracket for 12" LitePad LED fixture enables the fixture to be free-standing on any flat, level surface.
• Single Fade/Dimmer for LitePad Plug this Rosco Single Fader/Dimmer in between your LitePad panel and power source. It is calibrated, and capable of providing dimming between 0 - 100% without color shift.The elegant, ergonomic dimmer fits comfortably in the palm of your hand allowing easy use of the fade wheel -- perfect for camera applications and making continuous adjustments on the fly. An LED indicator confirms power to the LitePad is available and gives visual feedback about the current dimming level.
  • A maximum load of four amps allows multiple LitePads to be controlled from just one fader.
• Cinegel Swatchbook This is a 1.25 x 3.25" Swatchbook of Rosco Cinegel Series gels. Use this to pick the appropriate filters for your next purchase, or cut them out and tape them to small flash units. UPC: 053661105843

• Transformer for 3x3", 3x6", 6x6" LitePads (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• Transformer for 3x3", 3x6", 6x6" LitePads (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• Transformer for LitePads - 3 Amps (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• Transformer for 3x3", 3x6", 6x6" LitePads (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• Transformer for LitePads - 3 Amps (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• Transformer for LitePads - 3 Amps (120VAC)

• 10' Right Angle Extension Cable for LitePad

• Limited 1-Year Warranty

• 4A Fuse

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• 60 Day Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

• One Year Manufacturer's Warranty

Also Includes

• LitePad AA Battery Holder With DC Cord
• 3 x 1/4-20 Baby (5/8) Pin
• LitePad Case with Foam

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 3" Circle LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	3.0 x 0.4" / 7.6 x 0.9 cm
  Fixture Weight	0.10 lb / 0.05 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 0.3 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	3.25 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	6.8 x 6.6 x 3.0"

• 3 x 6" LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	3.0 x 6.0 x 0.4" / 7.6 x 15.2 x 0.9 cm
  Fixture Weight	0.30 lb / 0.14 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 0.5 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	6 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	6.772 x 6.772 x 2.835"

• 3 x 12" LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	3.0 x 12.0 x 0.4" / 7.6 x 30.5 x 0.9 cm
  Fixture Weight	0.55 lb / 0.25 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 0.8 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	9.75 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	12.5 x 12.5 x 2.9"

• 6 x 6" LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	6.0 x 6.0 x 0.4" / 15.2 x 15.2 x 0.9 cm
  Fixture Weight	0.55 lb / 0.25 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 0.7 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	7.75 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	6.8 x 6.8 x 3.0"

• 6 x 12" LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	6.0 x 12.0 x 0.4" / 15.2 x 30.5 x 0.9 cm
  Fixture Weight	1.10 lb / 0.50 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 1 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	12 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	12.7 x 12.5 x 2.8"

• 12 x 12" LitePad HO90 Daylight-Balanced LED Softlight

  Color Temperature	5300K
  Color Accuracy Standard	CRI 93
  Cooling System	None
  Dimming	Optional
  Display	None
  Housing Material	Acrylic
  Fixture Dimensions	12.0 x 12.0 x 0.4" / 30.5 x 30.5 x 0.9 cm
  Fixture Weight	2.15 lb / 0.98 kg

  Fixture Mount	None
  Accessory Mount	None

  AC Input Power	120 to 240 VAC, 50 / 60 Hz
  DC Input Power	12 VDC at 1.3 A
  Power Source	AC Adapter, External Battery
  Max Power Consumption	16 W

  IP Rating	IP61

  Box Dimensions (LxWxH)	12.6 x 12.5 x 2.8"

• Car Adapter for LitePad

  Box Dimensions (LxWxH)	3.7 x 3.4 x 0.8"

• Y-Cable for LitePad

  Box Dimensions (LxWxH)	6.0 x 4.5 x 0.4"

• 10' Right Angle Extension Cable for LitePad

  Length	10' (3 m)
  Output	12V DC 5 Amp max.

  Box Dimensions (LxWxH)	6.0 x 5.0 x 1.0"

• Four Way Splitter for LitePad

  Box Dimensions (LxWxH)	6.142 x 4.882 x 0.709"

• XLR, Four Pin Adapter Cable for LitePad

  Box Dimensions (LxWxH)	4.0 x 2.0 x 1.0"

• Anton Bauer Adapter for LitePad

  Box Dimensions (LxWxH)	6.8 x 6.1 x 0.6"

• Mounting Bracket for 3.0" LitePad

  Box Dimensions (LxWxH)	3.3 x 2.5 x 0.7"

• Mounting Bracket for 6" LitePad

  Box Dimensions (LxWxH)	6.0 x 5.0 x 1.25"

• Mounting Bracket for 12" LitePad

  Box Dimensions (LxWxH)	12.3 x 6.3 x 0.5"

• Single Fade/Dimmer for LitePad

  Input	11-15VDC
  Load Capacity	4A (48W) Max
  Dimensions	1.3 x 1 x 3" (3.3 x 2.5 x 7.7cm)

  Box Dimensions (LxWxH)	15.95 x 5.65 x 1.2"

• Cinegel Swatchbook

  Box Dimensions (LxWxH)	15.75 x 8.15 x 1.7"

Rating

Discussion
