User Manual for Royer Labs SF-2MP Active Ribbon Microphone Click to enlarge the picture
Contents of the user manual for the Royer Labs SF-2MP Active Ribbon Microphone
- Product category: Ribbon Microphones Royer Labs
- Brand: Royer Labs
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Royer Labs Ribbon Microphones
|
User manual for the Royer Labs SF-2MP Active Ribbon Microphone contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Royer Labs product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Royer Labs user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Royer Labs product will considerably shorten its lifespan!
|
Product description The SF-2MP Active Ribbon Microphone from Royer is a matched pair of SF-2 microphones. Designed primarily for classical applications and acoustic instruments, the SF-2 combines high-quality audio performance with active electronics for high output. The SF-2's output of -38 dB puts its sensitivity on par with that of phantom powered condenser microphones, allowing it to be used with a wide variety of mic pres regardless of gain characteristics. The mic uses custom designed FETs to deliver quiet operation, with self-noise of lower than 18 dB. The SF-2's magnet/pole piece transducer structure gives a wide, uniform frequency response and the 1.8-micron ribbon element is designed to deliver accurate transient response. The mic also is designed to provide accurate frequency response regardless of the angle of sound striking the ribbon and for low off-axis coloration. The electronics in the SF-2 provide the correct load to the ribbon element at all times, so its performance is never compromised by the effects of improper loading and regardless of the input characteristics of the mic-pre. Due to its low impedance output, SF-2 can be used on long cable runs with minimal signal loss. In addition, the mic is designed to resist ribbon element damage by phantom power, electrical glitches or miswired cables. - Phantom powered circuitry provides high output and impedance matching
- High SPL capabilities (130 dB @ 70 Hz)
- No distortion up to maximum SPL rating
- Extremely low residual noise
- Ribbon element not affected by heat or humidity
- Absence of high frequency phase distortion.
- Equal sensitivity from front and back of microphone
- Consistent frequency response regardless of distance
- High efficiency toroidal transformer and gold plated output connector
- Very low magnetic leakage
- Matte black finish reduces reflected light for live and on-camera use
UPC: 899060002501 In the Box Royer Labs SF-2MP Active Ribbon Microphone (Matched Pair, Standard Package) Aluminum Carrying Case SFS-2 Shockmount Mic Sock Limited Lifetime Warranty Limited 1-Year Warranty on Ribbon Table of Contents
|
Upload User Manual
Have you got an user manual for the Royer Labs SF-2MP Active Ribbon Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersRoyer Labs SF-2 Specs | | | Operating Principle | Pressure Gradient | | Transducer | Ribbon | | Tube | Yes | | Polar Pattern | Figure-8 | | Frequency Range | 30 Hz to 15 kHz | | Equivalent Noise Level | 20 dB | | Maximum SPL | 130 dB SPL | | Impedance | 200 Ohms | | Load Impedance | 1500 Ohms | | Sensitivity | -38 dBV/Pa | | | | Output Connectors | 1 x 3-Pin XLR | | Operating Current Consumption | 4 mA | | Operating Voltage | 48 V | | Length | 7.99" / 203 mm | | Diameter | 1.54" / 39 mm | | Weight | 1.02 lb / 465 g | | | | Package Weight | 8.4 lb | | Box Dimensions (LxWxH) | 16.0 x 14.5 x 9.0" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 55 owners. Add your rating and experience with the product.
