User Manual for Samson S-COM PLUS - Dual Mono Stereo Compressor Limiter with Expander Gate and De-Esser Click to enlarge the picture
Contents of the user manual for the Samson S-COM PLUS - Dual Mono
- Product category: Dynamics Processors Samson
- Brand: Samson
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Samson Dynamics Processors
|
User manual for the Samson S-COM PLUS - Dual Mono contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Samson product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Samson user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Samson product will considerably shorten its lifespan!
|
Product description The S com plus is a dual mono/stereo compressor designed to control signal levels in a variety of applications. The units logical design and layout make it simple to understand and easy to use. It offers distortion free audio with a predictable, usable range of control, whose effects range from undetectable to clearly identifiable. Each channel of the S com plus combines an expander/gate, compressor/limiter, enhancer and an adjustable de-esser with an independent LED meter. The compressor/limiter controls include threshold, ratio, attack, release and output. Or the user can switch to an auto function, which continuously analyzes the audio input and automatically adjusts the attack and release parameters based on the changing level. The de-esser improves audio quality by removing sibilance from vocals, or the "sizzle" from overly bright signal sources such as cymbals. The enhancer switch engages the EFR (Enhanced Frequency Recovery) circuit, which restores high frequencies that are sometimes diminished by heavy compression. A peak limiter with threshold control protects against clipping in the subsequent audio chain. The expander/gate features a variable threshold control and switchable (fast/slow) release time. The gate's operation is easily visible with twin LEDs. A Spectra switch on the S com plus enables a special circuit for high frequency contouring. Key input and key listen features provide for external triggering, or dynamically processing signals. - Dual mono/stereo compression/limiting with expander/gates, enhancer and de-esser
- Full control over compression threshold, ratio, attack and release
- Auto Envelope Generator
- Selectable AEG mode constantly adjusts the compressors attack and release times based on the program material
- Smart Knee Detector
- SKD circuit switches from soft to hard knee based on the level of input signal applied
- Peak limiter with independent threshold control and peak LED
- Expander/Gate with variable threshold control and switchable fast/slow release
- Adjustable de-esser with independent LED meter for reducing sibilance
- Spectral processing can be accomplished using the sidechain inputs and outputs
- 12 segment LED meters for input/output and gain reduction
- LED's on the gate show gate position open or closed
- Link button allows for the true stereo link operation
UPC: 809164001355 In the Box Samson S-COM PLUS - Dual Mono/Stereo Compressor/Limiter with Expander/Gate and De-Esser Power Cable Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Samson S-COM PLUS - Dual Mono Stereo Compressor Limiter with Expander Gate and De-Esser in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSamson SA-SCOMPLUS Specs | Function | Compressor/Limiter, Gate and De-Esser | | Number of Channels | 2 | | Inputs | 2 x XLR, 2 x 1/4" TRS phone
2 x 1/4" TS phone Sidechain | | Output | 2 x XLR, 2 x 1/4" TRS phone
2 x 1/4" TS phone Sidechain | | Maximum Input Level | +21dBu | | Compression Threshold | -40dBu to +20dBu | | Compression Ratio | 1:1 to infinity:1, variable | | Attack Time | 0.03ms to 300ms | | Release Time | 0.5ms to 5 Sec | | Gate Threshold | Off to +10dB | | Gate Rate | Attack: <1ms per 50db
Release: Fast or Slow | | Maximum Output Level | +21dBu | | Make-up Gain | -20dB to +20dB | | Frequency Response | 10Hz to 20kHz | | Dynamic Range | 116dBu | | Noise | Not specified by manufacturer | | Dimensions | 1U rack mount, 7 3/4" deep | | Specialties | Unit will operate at either +4dB or -10 dB, switchable | | | | Package Weight | 7.35 lb | | Box Dimensions (LxWxH) | 23.2 x 11.6 x 4.5" |
