Product description

If you go after a wide variety of game and take shots that can be measured in feet as well as hundreds of yards, the Schmidt & Bender 3-12x50 Zenith LM Riflescope is the ideal optic for you. Its large 50mm objective is capable of gathering copious amounts of light to ensure bright and clear images, and index-matched anti-reflection lens coatings that are custom-engineered to the glass used on the lens elements for maximum light transmission. A low 3x magnification ensures you don't lose the forest for the trees for the close shots, and keeping the max magnification to 12x helps to maintain image brightness and provides a wider field of view over higher-power scopes so you will always be able to discern your target in extreme low-light conditions.This version of the Zenith features 0.1 mrad windage and elevation impact point correction, and ±1.0 mrad elevation adjustment ranges. The scope's housing has a larger 30mm one-piece main-tube and is made of a lightweight aluminum alloy that has a scratch and corrosion-resistant matte-black anodized finish. The housing is nitrogen-filled to provide the Zenith with fogproof performance in all weather, and is O-ring sealed to be waterproof to 9.8 feet.
    Optical Performance
    • 3-12x zoom magnification
    • 42mm objective lens
    • Index-matched anti-reflection fully multicoated optics
    • Index matched coatings are custom-engineered to the properties of the glass elements to maximize light transmissions
    • 37.2-9.6' wide field of view at 100yd
    Reticle Details
    • Positioned on first (front) focal plane
    • Reticle and dot size maintains consistent reticle size and dot coverage at all zoom magnifications
    • FD4 modified duplex FlashDot reticle
    • Modified duplex crosshair design with long outer posts on horizontal and lower vertical axes and thin crosshairs in the center that extend straight up the vertical axis
    • Red illuminated FireDot aiming point that completely disappears when turned off for unobstructed view
    • Eleven adjustable FlashDot intensity levels
    • 'Off' positions between each intensity level for faster activation to preferred setting
    • Runs on one included CR2032 coin-cell battery
    • Automatically turns off after 6 hours of operation
    Use and Handling
    • 0.1 mrad/click impact point correction
    • ±1.0 mrad windage and elevation adjustment range
    • Covered windage and elevation turrets
    • Rubberized and knurled zoom collar
    • Fast-zoom mechanism goes from min to max in 180° rotation
    Construction Details
    • 30mm one-piece aluminum main-tube
    • Corrosion and scratch-resistant matte-black anodized finish
    • Nitrogen-filled. Fogproof and waterproof: Tested to 9.8'/3m
    • Manufactured by hand
    • Mount, rail, or rings required
In the Box Schmidt & Bender 3-12x50 Zenith LM Riflescope (FD4 FlashDot Reticle)
