Product description

Part of a line originally developed for the U.S. Special Operations Command, the Schmidt & Bender 5-45x56 PM II High-Power Riflescope is designed for shooting at extreme distances. Its large objective lens maximizes available light for a bright and detailed image.The 5-45x56 PM II High-Power Riflescope is equipped with an H2CMR illuminated reticle in the first focal plane. The scope can be adjusted for parallax from 32.8 yards to infinity. Its field of view at 100 yards ranges from 23' at 5x to 2.7' at 45x. The double-turn, lockable elevation turret offers an adjustment range of 270 cm at 1 cm per click, and navigating the range is made easier by the More Tactile Clicks feature—every tenth click is more pronounced. The single-turn, capped windage turret also features a zero stop.The scope's housing features a large 34mm one-piece maintube and is made of a lightweight aluminum alloy that has a scratch- and corrosion-resistant black anodized finish. The housing is nitrogen-filled to provide fogproof performance in all weather and O-ring sealed to be waterproof to 9.8 feet.
    Optical Performance
    • 5-45x zoom magnification
    • 56mm objective lens
    • Illuminated H2CMR reticle in first focal plane
    • Index-matched anti-reflection fully multi-coated optics
    • 23-3' field of view at 100 yards
    Use and Handling
    • 1 cm windage and elevation/click impact point correction
    • ±60 cm windage and 270 cm elevation adjustment range
    • Double-turn locking elevation turret with More Tactile Clicks feature
    • Single-turn capped windage turret with zero stop
    • Turrets rotate in counter-clockwise direction
    • Rubberized and knurled zoom collar
    Construction Details
    • 34mm one-piece aluminum maintube
    • Corrosion- and scratch-resistant black anodized finish
    • Nitrogen-filled. Fogproof and waterproof: Tested to 9.8'/3m
In the Box Schmidt & Bender 5-45x56 PM II High-Power Riflescope
  • 2032 Battery
  • Limited 2-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Schmidt & Bender 5-45x56 PM II High-Power Riflescope in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Schmidt & Bender 666-911-942-G8-E8 Specs

    Magnification 5 to 45x
    Objective Lens Diameter 56 mm
    Field of View 5x: 23.4' @ 100 yd / 7.8 m @ 100 m
    45x: 2.7' @ 100 yd / 0.9 m @ 100 m
    Exit Pupil Diameter 5x: 8.8 mm
    45x: 1.2 mm
    Eye Relief 3.5" / 90 mm
    Reticle Type H2CMR Reticle (First Focal Plane)
    Parallax Correction Yes, 32.8 yd / 30 m to Infinity
    Water Resistance Waterproof to 9.8' / 3 m
    Fogproof Yes, Nitrogen Filled
    Maintube Diameter 34 mm
    Battery None
    Dimensions Length: 17" / 43.4 cm
