Product description Hard Drives by Application: Which Is Best for You? Read More The 800GB 1200 2.5" SAS FIPS 140-2 SED Internal SSD (OEM) from Seagate features 800GB of secure storage and offers read speeds of up to 750 MB/s as well as write speeds of 500 MB/s. This allows it to be used for enterprise applications such as high-performance computing, online transaction processing, heavy data analytics, and more. To keep up the with the performance this drive offers, it is equipped with a custom designed controller with a SAS interface that transfers data at a rate of 12 Gb/s to your system. With reads up to 110,000 IOPS, you will notice the difference accessing data using this drive. Furthermore, this drive ensures data availability with redundant and failover I/O communication paths and protects data integrity with multiple layers of I/O error detection and correction.
This SSD is a business-friendly storage solution by offering SED technology that protects your data. This Self-Encrypting Drive automatically encrypts and decrypts all data to the drive while performing like any other solid-state drive. Because encryption is done on the drive, your overall system performance is not affected and your data is safe even if it is lost or stolen. Seagate has gone further to certify this drive with the FIPS 140-2 standard, which are requirements set by the U.S. government in encryption and security for sensitive, but unclassified use. This standard ensures the SSD uses sound security practices such as strong encryption algorithms and methods. In addition, FIPS 140-2 requires role-based authentication to use the SSD and has to have physical locks or tamper-evident seals. UPC: 763649047316 In the Box Seagate 800GB 1200 2.5" SAS FIPS 140-2 SED Internal SSD (OEM) Limited 5-Year Warranty Data Sheet PDF 890.8kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Seagate 800GB 1200 2.5" SAS FIPS 140-2 SED Internal SSD in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSeagate ST800FM0063 Specs | | | Interface | SAS III (12 Gb/s) | | Maximum Read Speed | 1200 MB/s | | Maximum Write Speed | 1200 MB/s | | Random Read Speed | 110,000 IOPS (4 KB Files) | | Random Write Speed | 40,000 IOPS (4 KB Files) | | Sequential Read Speed | 750 MB/s (128 KB Files) | | Sequential Write Speed | 500 MB/s (128 KB Files) | | | | Drive Type | SSD | | Form Factor | 2.5" (7 mm) | | | | Flash Memory Type | Multi-Level Cell (MLC) | | | | Annualized Failure Rate (AFR) | 0.44 % | | Encryption | FIPS 140-2 | | Endurance (Total Bytes Written) | 14,600 TB | | Non-Recoverable Read Errors per Bits Read | 1 in 1016 | | | | Power Draw | 4.05 W (Active)
3.0 W (Idle)
2.5 W (Standby) | | Current | 0.7 A at 5 VDC
0.4 A at 12 VDC | | | | Operating Shock | 1000 G / 0.5 ms | | Operating Vibration | 11.08 G / 20 to 2000 Hz | | Operating Temperature | 32 to 140°F / 0 to 60°C | | Storage Temperature | -40 to 167°F / -40 to 75°C | | Operating Humidity | 5 to 95% | | | | Dimensions (W x H x D) | 0.3 x 2.8 x 4.0" / 7.0 x 70.1 x 100.5 mm | | Weight | 3.5 oz / 100 g |
