Product description The EK 100 G4 Wireless Camera-Mount Receiver from Sennheiser is the latest addition to their evolution family of wireless microphones and is fully compatible with all previous series. Featuring an updated high-contrast LCD display, blue sync LED, and a dedicated escape button, it can be used when paired with a microphone and transmitter (sold separately) for capturing audio in live sound, broadcast, film, business, and educational applications.The EK 100 G4 wireless receiver is lightweight and built with an all-metal housing. It is equipped with 1680 tunable UHF frequencies and synchronizes with G4 transmitters at the touch of a button. A 3.5mm audio-output jack delivers a clean output signal using the included adapter output cables. The receiver operates on 2 standard AA batteries, and an optional 12 VDC adapter is also available. The included shoe-mount adapter allows you to mount the receiver on a camera for convenient portable use. - Updated Features
- The evolution wireless G4 retains all of G3's best features
Quicker setup
High-contrast LCD display
Dedicated escape button - Features
- Sturdy metal housing
42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception
Enhanced frequency bank system with up to 12 compatible frequencies
Adaptive-diversity for high-quality reception
Pilot tone squelch for eliminating RF interference when transmitter is turned off
Automatic frequency scan feature searches for available frequencies
Enhanced AF frequency range
Wireless synchronization of transmitters via infrared interface
User-friendly menu operation with more control options
Auto-Lock function avoids accidental changing of settings
HDX compander for crystal-clear sound
Operates on 2 standard AA batteries
Receiver features battery indication in 4 steps
Contacts for recharging BA 2015 accupack directly in the receiver
Wide range of accessories adapts the system to any requirement UPC: 615104309715 In the Box Sennheiser EK 100 G4 Wireless Camera-Mount Receiver A1: (470 to 516 MHz) CA2 Shoemount Adapter CL1 3.5mm to 3.5mm Output Cable for EW Series Camera-Mount Receiver CL-100 1/8"-M Mini to XLR-M 2 x AA Batteries Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sennheiser EK 100 G4 Wireless Camera-Mount Receiver A1: in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSennheiser EK 100 G4 Specs | Modulation | Wideband FM | | Frequency Band | A1: (470 to 516 MHz) | | Receiving Frequency | Maximum 1680 receiving frequencies, adjustable in 25 kHz steps
20 frequency banks, each with up to 16 factory-preset channels, no intermodulation
1 frequency bank with up to 12 programmable channels | | Switching Bandwidth | Up to 42 MHz | | Nominal/Peak Deviation | ±24 kHz / ±48 kHz | | Principle of Operation | Adaptive diversity | | Sensitivity | < 1.6 μV for 52 dBA eff S/N (with HDX, peak deviation) | | Adjacent Channel Selectivity | ≥ 65 dB | | Intermodulation Attenuation | Typically ≥ 65 dB | | Blocking | ≥ 70 dB | | Squelch | Low: 5 dBµV
Middle: 15 dBµV
High: 25 dBμV | | Pilot Tone Squelch | Can be switched off | | Antenna Inputs | 2 x BNC sockets | | Compander | Sennheiser HDX | | Signal to Noise Ratio | ≥ 110 dBA (1 mV, peak deviation) | | Total Harmonic Distortion (THD) | ≤ 0.9% | | Maximum AF Output Voltage | 1/8" /3.5 mm Jack: +12 dBu (mono, unbalanced) | | Output Level Range | 42 dB, adjustable in steps of 6 dB | | Temperature Range | 14 to 131°F (-10 to 55°C) | | Power Supply | 2 x AA 1.5 V batteries, or BA 2015 accupack | | Nominal Voltage | 3 V battery / 2.4 V rechargeable battery | | Current Consumption | Nominal Voltage: Typical 180 mA
With Receiver Switched Off: ≤ 25 µA | | Operating Time | Typically 8 hours | | Dimensions (L x W x H) | 3.2 x 2.5 x 0.9" / 82 x 64 x 24 mm | | Weight | 5.6 oz / 160 g | | | | Package Weight | 0.95 lb | | Box Dimensions (LxWxH) | 14.0 x 3.2 x 2.9" |
