User Manual for Sennheiser MKH-8020 Compact Omnidirectional Condenser Microphone Click to enlarge the picture
Contents of the user manual for the Sennheiser MKH-8020 Compact Omnidirectional Condenser Microphone
- Product category: Small Diaphragm Condenser Sennheiser
- Brand: Sennheiser
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Sennheiser Small Diaphragm Condenser
|
User manual for the Sennheiser MKH-8020 Compact Omnidirectional Condenser Microphone contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Sennheiser product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Sennheiser user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Sennheiser product will considerably shorten its lifespan!
|
Product description The MKH-8020 Omnidirectional Microphone from Sennheiser is a stereo set professional low-profile condenser microphones intended for crucial ambiance or close-microphone recording. The modular design consists of the MKHC-8020 omnidirectional capsule and the MZX-8000 XLR module output stage.The capsule features a symmetrical transducer with two back-plates resulting in extremely low distortion. The wide frequency response provides exceptional detail and transparency. With its pristine audio quality and compact design the MKH-8020 is ideal for orchestral recordings, instrument capturing, stereo recordings, etc. - Omnidirectional Pickup
- The omnidirectional polar pattern provides a generous pickup pattern at the direct and off-axis sections of the capsule. The pattern is ideal for use as a "mid" microphone in M/S stereo recording.
- Modular Design
- The modular design consists of the MKHC-8020 omnidirectional capsule and the MZX-8000 XLR module output stage.
- Symmetrical Transducer
- The capsule features a symmetrical transducer with two back-plates resulting in extremely low distortion.
- Wide Frequency Response
- A wide frequency response of 10Hz to 60kHz ensures accurate reproduction of instruments, ambiance, vocals, etc.
UPC: 615104131446 In the Box Sennheiser MKH-8020 Compact Omnidirectional Condenser Microphone (Stereo Set) 2 x MKH 8020 Microphone Heads 2 x MZX 8000 XLR Module for MKH-8000 Capsules yydwauauzsefersxwyxfac 2 x MZQ-8000 Standard Microphone Clip for MKH-8000 Microphones 2 x MZW-8000 Windscreen for MKH8000 Series Microphones Aluminum Transport Case Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sennheiser MKH-8020 Compact Omnidirectional Condenser Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSennheiser MKH-8020ST Specs | | | Polar Pattern | Omnidirectional | | Frequency Range | 10 Hz to 60 kHz | | Equivalent Noise Level | 10 dB A-Weighted
21 dB CCIR | | Maximum SPL | 138 dB SPL | | Impedance | 25 Ohms | | Load Impedance | 1000 Ohms | | | | Output Connectors | 1 x 3-Pin XLR | | Operating Current Consumption | 3.3 mA | | Operating Voltage | 48 V ± 4 V | | Operating Temperature | 14.00 to 140.00°F / -10 to 60°C | | Length | 2.95" / 75 mm | | Diameter | 0.75" / 19 mm | | Weight | 1.94 oz / 55 g | | | | Package Weight | 2.9 lb | | Box Dimensions (LxWxH) | 12.8 x 8.0 x 3.7" |
