Product description

• Sennheiser EM-XSW 1-A Table Top Receiver (A: 548 to 572 MHz) The EM-XSW 1-A Table Top Receiver from Sennheiser is designed to be paired with the XSW 1-A handheld microphone or bodypack transmitter with a lavalier microphone (sold separately). It can be used to capture audio for live stage applications and features internal, integrated antennas, as well as automatic frequency management, which offers up to ten coordinated frequency presets for wireless applications. The receiver is built to withstand even the toughest stress in everyday on-stage use and offers reliable transmission with easy-to-use set up. No matter whether you're a band, a theater, or at a seminar, the XS Wireless 1 receiver lets you do your thing and not worry about equipment.
  Great Performance and Price
  • The XS Wireless 1 receiver lets you concentrate on your talent and not the equipment. Just switch it on and its automatic frequency management does the rest. You can operate up to 10 coordinated frequency preset wireless connections.
  Live Sound
  • The receiver yields an open, natural sound. No lengthy set up—just go!
  Reliable Transmission
  • On stage, you must put up with a lot of things—so does your equipment. XS Wireless 1 is built to last: Receivers are designed to withstand even the toughest stress in everyday on-stage use.
  UPC: 615104281820
• Sennheiser SK-XSW-A Bodypack Transmitter (A: 548 to 572 MHz) The SK-XSW-A Bodypack Transmitter from Sennheiser is designed to be paired with an EM-XSW1-A receiver (sold separately). It can be used to capture audio for live stage applications and features automatic frequency management, which offers up to ten coordinated frequency presets for wireless connections. The transmitter is sweat-resistant and can withstand even the toughest stress in everyday on-stage use.
  Great Performance and Price
  • The XS Wireless 1 lets you concentrate on your talent—and not the microphone equipment. Just switch it on and its automatic frequency management does the rest. You can operate up to ten wireless connections simultaneously.
  Live Sound
  • The transmitter yields an open, natural sound. No lengthy set up—just go!
  Reliable Transmission
  • On stage, you must put up with a lot of things—so does your equipment. XS Wireless 1 is built to last: Transmitters are sweat-resistant and withstand even the toughest stress in everyday on-stage use.
  UPC: 615104281998
• Senal UEM-155-35H-BE Omni Earset Microphone with 3.5mm Locking Connector for Sennheiser Transmitters (Beige) The Beige UEM-155-35H-BE Omnidirectional Earset Microphone with 3.5mm Locking Connector for Sennheiser Transmitters from Senal is a low-profile, lightweight, and miniature hands-free microphone with a flexible boom arm that can be worn on either ear. It can be used to deliver rich, accurate, and natural-sounding audio in vocal and speech applications for theater performances, lectures, houses of worship, and more. The adjustable ear loop comfortably conforms to your ear, and the boom can be precisely placed to deliver an accurate sound. The UEM-155 microphone capsule is optimized to capture rich and natural-sounding speech or vocals, and provides high gain before feedback. The microphone's proximity to the mouth assures accuracy and clarity.
  For Sennheiser Bodypack Transmitters
  • The UEM-155 features a 3.5mm Locking connector for connectivity with Sennheiser Bodypack Transmitters. The four-foot cable is long enough that it won't restrict your movements while speaking or performing.
  Speech and Vocals
  • The UEM-155 is optimized for the voice. It features a rich and natural sound, whether you're speaking or singing. Proximity to the microphone limits volume fluctuations and assures that the mic is always in a suitable position to capture your voice.
  Omnidirectional Polar Pattern
  • The miniature omnidirectional capsule ensures low sensitivity to vocal pops or plosives. Its accurate and natural sound eliminates the proximity effect, which can make your voice sound deep and boomy as you move closer to the microphone.
  Low Profile
  • Thanks to the narrow mic boom, an earpiece that tucks neatly behind your ear, and the option of black or tan colors, the UEM-155 is inconspicuous and won't be a distraction to your audience.
  High Gain Before Feedback
  • The UEM-155 has been optimized to drastically reduce the possibility of feedback that can interrupt programs and performances. This microphone can tolerate high levels of amplification, so you can use it in large rooms or when performing on a loud, live stage environment.
  Windscreen and Clothing Clip
  • For the quietest performance, the included windscreen minimizes unwanted noise from wind or moving air. The clothing clip affixes the mic cable to clothes and prevents handling or cable noise.
  UPC: 847628002173

• EM-XSW 1-A Table Top Receiver (A: 548 to 572 MHz) eqzdvrrtwettzszvcxtvewuf
• Limited 2-Year Warranty

• SK-XSW-A Bodypack Transmitter (A: 548 to 572 MHz)

• Senal - UEM-155-35H-BE Omni Earset Microphone with 3.5mm Locking Connector for Sennheiser Transmitters (Beige)
