Product description

• Sennheiser XSW2-CI1 Wireless 2 Instrument System (A: 548 to 572 MHz) The XSW2-CI1 Wireless 2 Instrument System features a true diversity receiver, a compact bodypack transmitter, and a robust instrument cable with a 1/4" jack. It has 12 compatible channels and is offered as an easy to use, all-in-one wireless system for electric bass, guitar, and keyboard instruments for live-sound applications. The unit is built with automatic frequency management and synchronization so you don't have to scramble to find an available channel. The system offers an intuitive LCD display, two external antennas, a compact bodypack transmitter, and an instrument cable. Additionally, built with a metal receiver housing, the system also includes a rackmount kit, power supply, carry pouch, and two AA batteries.
  • True diversity receiver with metal housing
  • External antennas
  • Automatic frequency management and synchronization
  • Remote channel for easy setup
  • Fully tunable over a wide range of UHF frequencies
  • Rackmount kit included
  • Up to 12 compatible channels
  UPC: 615104279759
• Senal OLM-2 Lavalier Microphone with 3.5mm Connector for Sennheiser ew & Senal AWS-2000 Series This Senal OLM-2 Lavalier Microphone is a high-performance professional lavalier microphone with a locking 1/8" connector for Sennheiser ew and Senal AWS-2000 wireless transmitters. Its miniature, lightweight design allows for discrete placement without compromising sound quality. This versatile workhorse microphone is ideal for broadcast, video, and stage applications.

  Utilizing a broadcast-quality electret condenser element, it features a smooth frequency response and a wide dynamic range. Its omnidirectional polar pattern enables 360° sound pickup, capturing a natural blend of voice and ambiance with low sensitivity to wind and handling noise, as well as to vocal plosives. In addition to being designed to connect to a Sennheiser or Senal bodypack transmitter, the OLM-2 can be combined with the Senal PS-48B Power Supply (sold separately) to operate on phantom or battery power, enabling it to plug into any XLR microphone input.
  • Gold-plated locking 1/8" connector for Sennheiser ew and Senal AWS-2000 wireless transmitters
  • Metal windscreen reduces wind noise and vocal plosives
  • Tie clip for securing mic to clothing
  • 16.3 x 6.5mm (length x diameter) head size
  UPC: 847628562639

• XSW2-CI1 Wireless 2 Instrument System (A: 548 to 572 MHz) utxfxqxuyx
• EM-XSW 2 Receiver
• SK-XSW Bodypack Transmitter
• 1/4" to 1/8" Instrument Cable
• 2 x AA Batteries
• NT 12-5 CW Power Supply
• Rackmount Kit
• Protective Pouch
• Limited 2-Year Warranty

• Senal - OLM-2 Lavalier Microphone with 3.5mm Connector for Sennheiser ew & Senal AWS-2000 Series

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Sennheiser XSW2-CI1 Wireless 2 Instrument System (A: 548 to 572 MHz)

  Modulation	Wideband FM
  Frequency Range	A: 548 to 572 MHz
  Switching Bandwidth	Up to 24 MHz
  Frequencies	Adjustable in 25-kHz steps 8 frequency banks, each with up to 12 factory-preset channels
  Signal to Noise Ratio	≥ 103 dBA
  Total Harmonic Distortion (THD)	≤ 0.9%
  Temperature Range	Operation: 32 to 104°F (0 to +40°C) Storage: -4.0 to 158°F (-20 to +70°C)
  Transmitter Synchronization	2.4 GHz, low power OQPSK (only active during synchronization)

  Principle of Operation	Double superheterodyne
  Diversity Method	True diversity
  Sensitivity	< 3 µV at 52 dBA rms S/N at (peak deviation)
  Frequency Response	50 Hz to 16 kHz (-3 dB)
  Maximum AF Output Voltage	At peak deviation, 1 kHz AF 1/4" (6.3 mm) Jack Socket (Unbalanced): +6 dBu XLR Socket (Balanced): +12 dBu At peak deviation, 1 kHz AF
  Adjustment Range	Audio: 40 dB, adjustable in 5-dB steps
  Power Supply	12 VDC nominal/300 mA
  Squelch	Adjustable from 3 dBμ V to 28 dBμ V (combined with pilot tone)
  Line/Mic Level	20 dB, switchable
  Housing Material	Rugged metal housing
  Dimensions (W x H x D)	7.9 x 1.7 x 5.0" (200 x 42 x 127 mm)
  Weight	24 oz (680 g)

  RF Output Power	10 mW
  AF Frequency Response	50 Hz to 16 kHz (Line) 80 Hz to 16 kHz (Mic)
  Audio Input	1/8" (3.5 mm) jack socket
  Input Voltage	Maximum at 3% THD: Mic: Typ. 1.5 V rms Line: Typ. 2.6 V rms @ -30 dB gain
  Power Supply	2 x AA size batteries, 1.5 V
  Operating Time	Approximately 10 hours
  Sensitivity Adjustment	Range: 0 to -30 dB, adjustable in 10-dB steps
  Housing Material	Rugged ABS housing
  Dimensions (W x H x D)	2.8 x 3.8 x 1.1" (71 x 96 x 28 mm) approximate
  Weight	3.4 oz (95 g) approximate

  Box Dimensions (LxWxH)	13.6 x 13.4 x 3.4"

• Senal OLM-2 Lavalier Microphone with 3.5mm Connector for Sennheiser ew & Senal AWS-2000 Series

  Transducer	Electret condenser
  Polar Pattern	Omnidirectional
  Frequency Response	50 Hz to 20 kHz
  Sensitivity	-63 dB ±3 dB (0 dB = 1 v/microbar @ 1 kHz)
  Impedance	15,000 Ω ±30% @ 1 kHz
  Operating Voltage	1 - 10 VDC
  Connector	Gold-plated 1/8" (3.5 mm) locking connector jack
  Cable Length	5.3' (1.6 m)
  Head Diameter	0.3" (6.5 mm)
  Head Length	0.6" (16.3 mm)
  Total Weight	1 oz (28.3 g)

  Box Dimensions (LxWxH)	3.4 x 3.3 x 1.6"
