User Manual for Sequential Prophet 12 Module - Hardware Synthesizer Module Click to enlarge the picture
Contents of the user manual for the Sequential Prophet 12 Module - Hardware
- Product category: Synthesizer Modules Sequential
- Brand: Sequential
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Sequential Synthesizer Modules
|
User manual for the Sequential Prophet 12 Module - Hardware contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Sequential product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Sequential user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Sequential product will considerably shorten its lifespan!
|
Product description The Prophet 12 Module from Dave Smith Instruments is a synthesizer module that delivers the same power and sound as the Prophet 12 Keyboard. Each of the twelve voices is composed of a hybrid digital/analog architecture that sounds different from the other DSI synthesizers, yet retains the true Prophet vibe. The brand new hybrid voice has a digital front end followed by an all-analog signal path output.
Each voice has five high-resolution digital oscillators, a digital character effects section, a resonant Curtis low-pass filter, a high-pass filter, and a tune-able feedback circuit. Also available is a four-tap delay line with feedback per line, four loopable five-stage envelope generators, and four syncable LFOs with slew and phase offset. A sophisticated arpeggiator and a sixteen-slot modulation matrix with twenty-six modulation sources and ninety-seven modulation destinations provide further versatility.
The streamlined interface with a sharp OLED display allows for quick and easy control of every parameter on the synthesizer. Easily create modulation assignments using the Assign Mod buttons. Dedicated low- and high-pass filter potentiometers provide quick and smooth control of the filters. Extensive MIDI implementation covers every available parameter on the instrument with dedicated MIDI I/O along with USB MIDI. The module is housed in a rugged steel enclosure. - Prophet 12 Module provides the same sound as the Prophet 12 Keyboard
- Each of the voices utilizes a hybrid digital/analog architecture featuring a digital front end followed by an analog signal path output
- Each voice has five high-resolution digital oscillators, a digital character effects section, a resonant Curtis low-pass filter, a high-pass filter, and a tune-able feedback circuit
- Each voice has a four-tap delay line with feedback per line, four loopable five-stage envelope generators, four syncable LFOs with slew and phase offset, an arpeggiator, and a sixteen-slot modulation matrix
- Freely assign oscillators in whatever operator and modulator configurations are desired
- Assign each of the oscillators to modulate LFOs, envelopes, and filters
- Streamlined interface provides quick and easy control of every parameter on the synthesizer
- Easily create modulation assignments using the Assign Mod buttons
- Dedicated low- and high-pass filter potentiometers provide quick and smooth control of the filter
- Extensive MIDI implementation covers every available parameter on the synthesizer - easily pair it with a favorite MIDI controller or DAW
- Rugged steel enclosure equally at home on a desk, in a rack, or on stage
- Oiled walnut wood end panels
UPC: 855346000814 In the Box Sequential Prophet 12 Module - Hardware Synthesizer Module External Power Supply One (1) Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sequential Prophet 12 Module - Hardware Synthesizer Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSequential DSI-1300 Specs | Oscillators | 5 x DSP-based oscillators per voice (including one sine wave sub oscillator)
4 x Classic wave shapes (saw, square, triangle, sine) per oscillator
12 x Selectable complex shapes per oscillator
3 x Noise types per oscillator: white, pink, violet
Analog VCAs
Shape modulation
Oscillator cross modulation: frequency modulation (FM) and amplitude modulation (AM)
Hard sync on each of the four oscillators | | Effects | 5 x Digital effects
Girth and Air: High- and low-shelf EQ with harmonic excitement
Hack and Decimate: Sample and bit rate reduction
Drive: Soft saturator for adding soft distortion and harmonic content to the signal | | Filters | Curtis 2- or 4-pole resonant analog low-pass filter (self oscillates in 4-pole mode) per voice
2-pole resonant analog high-pass filter per voice | | Feedback and Delay | Tuned feedback
Four-tap syncable multi-delay with feedback and amount per delay per voice | | Envelopes | 4 x Delay + ADSR envelopes (LPF, VCA, and two auxiliary envelopes)
Auxiliary envelopes 3 and 4 freely assignable to multiple modulation destinations
All envelopes can repeat/loop | | LFO | 4 x Syncable LFO's with phase offset and slew per LFO | | Modulation | 16 x 2 Modulation matrix with 26 modulation sources and 97 modulation destinations
Modulation assignment buttons for quick and easy modulation routing | | Arpeggiator | Programmable, with up, down, up+down, random, assign modes
Re-latching | | Distortion | Independent programmable stereo analog distortion per layer | | Controls | 12 x Knobs
34 x Buttons
OLED display (easily visible in low light situations and from multiple angles) | | Memory | 396 x Factory programs
396 x User programs
Direct program access using numeric keypad and dedicated user, factory, and bank buttons
Playlist mode
4 x Playlists with up to 40 programs each | | Connections | 2 x 1/4" TS Main Stereo Out
2 x 1/4" TS Layer B Stereo Out
1 x 1/4" TRS Headphone
1 x 1/4" TS Sustain/Footswitch
2 x 1/4" TRS Expression Pedal
3 x 5-pin DIN MIDI In, Out, Thru
1 x USB Type B for bidirectional MIDI communication | | Power Requirements | 100~240 VAC, 50/60 Hz for included power adapter | | Dimensions (WxDxH) | 16.5 x 6.8 x 2.9" (419 x 173 x 72 mm) | | Weight | 4.9 lb (2.2 kg) | | | | Package Weight | 7.35 lb | | Box Dimensions (LxWxH) | 21.6 x 10.2 x 5.3" |
