User Manual for SHAPE ARRI Standard Studio Bridgeplate and 12" Dovetail Plate with 15mm Rods Click to enlarge the picture
Contents of the user manual for the SHAPE ARRI Standard Studio Bridgeplate and
- Product category: Camcorder Supports & Rigs SHAPE
- Brand: SHAPE
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for SHAPE Camcorder Supports & Rigs
 |
User manual for the SHAPE ARRI Standard Studio Bridgeplate and contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any SHAPE product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official SHAPE user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a SHAPE product will considerably shorten its lifespan!
|
Product description Use the aluminum ARRI Standard Studio Bridgeplate and 12" Dovetail Plate with two tapered, 12" 15mm rods to easily mount and unmount your camera and accessories. The studio-offset rods are spaced 100mm apart. One 1/4"-20 and one 3/8"-16 screw allow mounting a variety of cameras, and the plate locks and slides up and down the rods with the use of a locking lever.
The studio bridgeplate is attached by 1/4"-20 and 3/8"-16 screws to an aluminum, Teflon-coated ARRI standard dovetail plate. The 12" plate has a tapered ARRI dovetail that allows you to adjust your bridgeplate by easily sliding back and forth. A stopper screw on one end and a safety latch on the other prevent the bridgeplate from accidentally sliding off the plate. There are twelve 1/4"-20 and five 3/8"-16 threads down the center of the plate for mounting.
A flat screwdriver is provided to tighten the mounting screws, and it can be attached to the bridgeplate with a magnet. UPC: 629266008331 In the Box SHAPE ARRI Standard Studio Bridgeplate and 12" Dovetail Plate with 15mm Rods ARRI Standard 12" Dovetail Plate 1/4"-20 Captive Screw 3/8"-16 Captive Screw 2 x 15mm Rod Flat Screwdriver Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the SHAPE ARRI Standard Studio Bridgeplate and 12" Dovetail Plate with 15mm Rods in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSHAPE DPK15 Specs | Material of Construction | CNC-machined aluminum | | Mounting Threads | 1/4"-20 and 3/8"-16 | | Rod Standard | 15 mm | | Rod Length | 12" / 30.5 cm | | Rod Spacing | 100 mm | | Dimensions | 12.2 x 5.4 x 2.1" / 30.5 x 13.6 x 5.3 cm | | Weight | 3 lb / 1.4 kg | | | | Package Weight | 3.55 lb | | Box Dimensions (LxWxH) | 12.9 x 11.1 x 2.4" |
