Product description The Shinybow SB-5610 HDMI ARC Control Box with HDMI Audio Extractor can link audio (ARC or Source SPDIF) to TV or an audio amplifier and turn the TV or audio amplifier speaker on or off. The audio extractor supports the use of an HDMI repeater and equalizer between the HDMI player and the display. SB-5610 supports HDMI 1.3a, 1.3c (CTS), HDCP 2.0, and DVI 1.0 compliant HDMI 1.4a, 3D formats. This device allows you to extract analog audio LPCM2 and digital audio SPDIF from the HDMI signal while still sending the original audio-video signal to your HD devices. When using a display without speakers, you can still extract the analog audio to external speakers or digital audio to an amplifier. - HDMI ARC control box with source SPDIF and analog audio extractor
- HDMI 1.3a, HDMI 1.3c (CTS), DVI 1, and HDCP compliant
- Supports HDMI in/out repeater with equalizer
- Supports 3D video format in HDMI 1.4
- Supports SD/HD digital audio 2-channel IIS/DSD and SPDIF audio
- Supports 12-bit HDMI deep color up to 1080p (225 MHz TMDS clock)
- Supports HD (high-definition) resolutions of HDMI 408p, 720p 1080i/1080p
- Supports DVI resolutions up to UXGA (1920 x 1200)
- Digital Audio SPDIF format with DTS 5.1, Dolby 5.1 & PCM2
- Select to turn on or off the TV or audio amplifier speaker
- Cable support in/out distance 49.2' (15 m) (depends on the HDMI cable quality)
- Wall mountable; easy mounting
In the Box Shinybow SB-5610 HDMI ARC Control Box with HDMI Audio Extractor User Guide 12 VDC, 300 mA AC/DC Adapter 3-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Shinybow SB-5610 HDMI ARC Control Box with HDMI Audio Extractor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersShinybow SB-5610 Specs | HDCP Compliant | HDMI 1.3a, HDMI 1.3C (CTS), DVI 1.0, DDC 5 Vpp | | Support | Compliant with HDCP 1.4 specification | | Video Support | 1080p HDMI format and DVI 1920 x 1200 resolution, Digital RGB 12-bit format deep color, TMDS clock | | Audio | Audio Port: PCM-2CH
S/PDIF Port: DTS 5.1, Dolby 5.1, PCM-2CH
HDMI Port: PCM-2CH, PCM 7.1, DTS 5.1, Dolby 5.1, Dolby Digital 7.1, DTS HD7.1, MAP (MLP) 7.1, one-bit audio (2-channel) | | Analog Audio | LPCM2 | | 3D | 3D video format in HDMI 1.4 (223 MHz) | | Frequency Range | HDMI 25 to 225 MHz TMDS clock | | ARC (Audio Return Channel) | Audio return channel via TV HDMI ARC port | | Digital Audio Extraction | Turn on or off the TV or audio amplifier speaker | | Cable Distance | In/out 49.21' (15 m), total 98.42' (30 m) depending on HDMI cable quality | | Safety Approvals | CE, FCC, RoHS (2002/95/EC) | | Power Supply | Universal switch power supply, +12 VDC / 300 to 1000 mA | | Dimensions (L x W x H) | 4.95 x 3.14 x 1" (130 x 80 x 25 mm) | | | | Package Weight | 1.6 lb | | Box Dimensions (LxWxH) | 9.7 x 6.9 x 2.2" |
