Product description The Shinybow SB-6225 HDMI Amplifier Repeater Extender extends the reach of HDMI signals up to 100’ (30.48 m). In its basic configuration, the SB-6225 links 2 HDMI cables together to create a longer extension, as easily as connecting 2 cables up to 100’ (30.48) on each repeater. Alternately, SB-6225 repeaters can be daisy chained to create much longer HDMI extensions up to 360’ (109.72 m).
The SB-6225 repeater for HDMI supports both the legacy HDMI version 1.2 features and the HDMI version 1.3 features such as 3D, deep color, 1080p HD resolution, and 8-channel digital audio for good signal quality.
Standard installation involves using an HDMI cable up to 50’ (15.24 m) long connected from an HDMI source (DVD player, set-top box, gaming console) to the HDMI input jack on the SB-6225. A second HDMI cable runs from the SB-6225 repeater output jack to the HDTV display up to 50’ (15.24 m) away. The 12 VDC power supply is plugged into a nearby wall socket and into the repeater unit. - HDMI digital video / audio and DVI format and HDCP compliant
- Supports link speed of up to 3.4 Gbps
- Support digital RGB 36 bits HDMI TMDS format deep color
- Extension with high-quality video 1920 x 1200 for 1080p-60
- Supports HD (high-definition) resolution 408, 720p 1080i / 10810p
- Supports high-quality digital audio format with DTS-HD master audio, Dolby True-HD & Dolby
- Long distance extension between Blu-Ray HDMI player and HDMI display
- Easy to install without any adjustment
- Easy mounting; wall mountable
- Power 12 VDC input with low power consumption
In the Box Shinybow SB-6225 HDMI Amplifier Repeater Extender User Guide AC/DC Adapter (12 VDC, 300 mA) Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Shinybow SB-6225 HDMI Amplifier Repeater Extender in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersShinybow SB-6225 Specs | Extender | Type: HDMI signal for distance 100' (30 m) extender | | I/O Ports | Input: 1x HDMI (Digital Video - TMDS, Digital Audio) with HDCP Output: 1x HDMI (Digital Video - TMDS, Digital Audio) with HDCP | | Video Signals | Input: Digital Video (TMDS) 0.5 to 1 Vpp, DDC 5 Vpp | | Signals Supported | HDMI standard, DVI, and HDCP compliant | | Video Supported | 1080p HDMI format and DVI 1920 x 1200 resolution
Digital RGB 36 bits HDMI TMDS format deep color | | Audio Supported | TS-HD Master Audio, Dolby True-HD and Dolby
Digital Plus | | Support | HD Resolution: 408p, 720p 1080i/1080p | | Distance | 100' (30.48 m) | | Safety Approvals | CE, FCC, RoHS (2002 / 95 / EC) | | Power Source | Universal switch power supply +12 VDC / 0.42 mA | | Size | 2.3 x 1.7 x 1" (80 x 40 x 25 mm) | | | | Package Weight | 0.75 lb | | Box Dimensions (LxWxH) | 5.6 x 5.2 x 2.4" |
