Product description

Updated Features
• • Improved audio quality (without changing sound signature)
  • Improved RF performance and reliability
  • Improved battery life with alkaline AA batteries (thanks to new headphone amp technology)
  • Updated firmware with new features and workflow improvements
  • Improved Volume Limiter function (selectable ranges of limiting increased)
  • 4-band parametric EQ added
  • Power-Save Mode added (similar to feature on PSM300 series packs)

Unparalled Audio Quality
• • Bodypack receivers with advanced digital signal processing technology deliver more headroom, improved stereo separation, and higher audio fidelity

Robust RF Performance
• • P9RA+ bodypack receivers offer enhanced signal reception and range
  • Precision front-end RF filtering significantly reduces RF interference for a cleaner, stronger RF signal, fewer dropouts, and fewer audible artifacts

Setup and Operation Features
• • CueMode allows monitoring of different stage mixes and storing of up to 20 separate channels on one bodypack for quick and easy reference
  • Scan and Sync scans the RF environment with the bodypack and assigns an identified group and channel to your system over wireless IR link
  • MixMode technology combines two separate audio channels for simultaneous listening in both ears, or can transmit two independent IFB program feeds
  • Four-band parametric EQ gives you the choice to adjust frequencies for a fully customized sound
  • Input EQ Presets give you the option to further tailor your sound, including the option to make the P9RA+ sound like the P9RA with a designated “Match” setting

Rechargeability Options
• • The SB900A lithium-ion rechargeable battery provides extended usage times and precise tracking of remaining life and charge cycle details
  • The SCB800-US eight-bay charger brings up to eight SB900 batteries to full charge within two hours and has charge status LEDs for each battery
  • The SBC200 dual-docking charger works with SB900A, P9RA+, P10R+, QLX-D® Digital Wireless Systems, and ULX-D® Digital Wireless Systems, available with and without power supply
  • The SBC220 networked dual-docking charger works with SB900A, PSM 900 (P9RA+ only), PSM 1000 (P10R+ only), QLX-D Digital Wireless Systems, ULX-D Digital Wireless Systems, and Axient Digital (AD1 and AD2 only), available with and without power supply. When the SBC220 is connected to a network, battery information for each transmitter can be viewed remotely
  UPC: 042406542166 In the Box Shure P9RA+ Wireless Bodypack Receiver (G6: 470 to 506 MHz)
• 2 x Antennas
• Removable AA Battery Adapter
• Limited 2-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

Shure PSM 900 Specs

Frequency Band	G6: 470 to 506 MHz
RF Filter Range	-3 dB at 30.5 MHz from the center frequency of each band
RF Gain	Active: 31 dB (adjusts RF sensitivity to provide more RF dynamic range)
RF Sensitivity	2.2 μV (20 dB SINAD)
Image Rejection	>90 dB
Adjacent Channel Rejection	>70 dB
Squelch Threshold	22 dB SINAD ( Rating 60% users recommend this product to others. And what about you? This product has already been rated by 79 owners. Add your rating and experience with the product. Discussion Ask our technicians if you have a problem with your settings, or if anything is unclear in the user manual you have downloaded. You can make use of our moderated discussion. The discussion is public and helps other users of our website who may be encountering similar problems. The discussion is empty - enter the first post Post a new topic / query / comment: Items marked with * are required. Your name *: E-mail : Subject *: Message *: Your email address will not be displayed. Do not forget to fill it in if you want to receive a reply to your enquiry/contribution. Processing of personal data in accordance with GDPR
