Product description The SKAARHOJ MC2 Module is a programmable control surface for use with broadcast video hardware, providing tactile control over essential functions. As a "Module" unit, this MC2 has DB-9 ports on either side. The right side connects to a Master unit or other Module units in the chain, while the left side can connect more Module units to expand the control surface. A short DB-9 cable can be used to connect Module units for a second operator. Using the SKAARHOJ-developed open-source UniSketch OS, the end-user can program the 23 backlit buttons and slider on the MC2 to control a variety of devices, from switchers and recorders to PTZ cameras and playback decks. A single SmartSwitch with a built-in scribble strip can be reprogrammed for multiple functions in real-time. System-state information is displayed on the built-in LED display. In the Box SKAARHOJ MC2 Module Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the SKAARHOJ MC2 Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSKAARHOJ MC Series Specs | Dimensions | 9.1 x 4.2 x 1.4" / 23 x 10.7 x 3.5 cm | | Weight | 1.4 lb / 640 g |
