User Manual for SLR Magic Cine 35mm T1.4 Mark II Lens with E Mount and 52mm Variable ND Kit

• Product category: Digital Cine Lenses SLR Magic
• Brand: SLR Magic
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for SLR Magic Digital Cine Lenses

Product description

• SLR Magic Cine 35mm T1.4 Mark II Lens with Sony E-Mount The SLR Magic Cine 35mm T1.4 Mark II Lens with Sony E-Mount supports cine-style shooting on a camera with a Sony E-Mount. It features a fast T1.4 to T16 aperture range with a clickless iris that allows smooth pulls, and geared focus and aperture rings.

  The lens follows the industry standard focus rotation, so when working with an optional follow focus unit there is no need to make an adjustment to how you work or add a reversing gear. The lens front does not rotate as you focus the lens; this allows you to use optional accessories such as clip-on matte boxes, or the SLR Magic Anamotphot adapter. The mark II features stronger mechanical components than the mark I version of the lens, allowing you to use the optional SLR Magic Anamporphot adapter or achromatic diopters without requiring an optional lens support.
  Coverage
  • The lens has a 35mm equivalent focal length of 52mm
  • The clickless iris allows you to smoothly adjust your exposure during the shot.
  • Built-in iris and focus gears follow industry standards, allowing you to work with optional follow focus units and lens gear motors.
  • Focus rotation of the lens follows the cinema standard, allowing you to swap between this and other optional lenses without having to change your workflow.
• SLR Magic 52mm Self-Locking Variable Neutral Density 0.4 to 1.8 Filter (1.3 to 6 Stops) The SLR Magic 52mm Self-Locking Variable Neutral Density 0.4 to 1.8 Filter is a solid variable neutral density filter that is designed to mount onto lenses with 52mm front filter threads and provides an exposure reduction of 1.3 to 6 stops. The 0.4 to 1.8 density creates a darkening of the entire image, allowing you to photograph with a wider aperture or slower shutter speed than normally required. The degree of density is easily controlled by rotating the front filter ring, helping you to predetermine the additional exposure length required. By slowing your exposure time or increasing your aperture, you are able to control depth of field and convey movement more easily. For easier, repeatable control over density settings, the front ring is visually demarcated with numbers representing different density values and includes a rotation lever to further enable fast and precise positioning of the front ring. Once the front ring is rotated into a position that corresponds to the desired amount of density, the filter's rear ring can then be turned to lock the front ring into place, helping to ensure consistent exposures.

  This filter is constructed from optical glass for clarity and color fidelity. It is multi-coated to prevent internal ghosting as well as reflections and also features a 62mm mount which helps to reduce the likelihood of vignetting when used with wide-angle lenses.
  • Variable neutral density filter allows you to dial in differing amounts of density scene to scene.
  • 0.4 to 1.8 neutral density filter darkens the image, allowing you to photograph with a longer shutter speed or wider aperture than normally required.
  • Providing a reduction of 1.3 to 6 stops, this filter allows you to control depth of field and convey movement more easily.
  • Offers increased flexibility to use specific ISO settings or ISO films under bright ambient light.
  • Provides increased exposure flexibility while using cinema or video cameras within a designated film frame rate.
  • Multi-coated, optical glass for clarity and color fidelity as well as the prevention of internal ghosting and reflections.
  • Side lever allows the filter glass to be easily rotated.
  • Integrated exposure locking ring prevents accidental rotation of filter glass and changes to corresponding density values.
  • 62mm front mount helps to reduce the likelihood of vignetting with wide-angle lenses.
  • Plastic filter case for storage and transport.

• Cine 35mm T1.4 Mark II Lens with Sony E-Mount
• Front Lens Cap
• Rear Lens Cap
• Limited 1-Year Warranty

• 52mm Self-Locking Variable Neutral Density 0.4 to 1.8 Filter (1.3 to 6 Stops)

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• SLR Magic Cine 35mm T1.4 Mark II Lens with Sony E-Mount

  Focal Length	35mm
  Lens Mount	Sony E
  Format	Super35/APS-C
  Maximum T-Stop	T1.4
  Minimum T-Stop	T16
  Minimum Focus Distance from Image Plane	11.8" / 30 cm
  Gear MOD & Pitch	Focus: 0.8 MOD / 32 Pitch Iris: 0.8 MOD / 32 Pitch
  Filter Thread	52 mm
  Length	2.8" / 70.3 mm
  Weight	13.1 oz / 370.0 g

  Box Dimensions (LxWxH)	5.4 x 5.3 x 5.2"

• SLR Magic 52mm Self-Locking Variable Neutral Density 0.4 to 1.8 Filter (1.3 to 6 Stops)

  Filter Type	Variable ND
  Density	0.4 (1.3 Stops) to 1.8 (6 Stops)
  Shape	Circle
  Circular Size	52 mm
  Front Accessory Thread / Bayonet	62 mm
  Filter Material	Glass
  Coatings	Multi-Coating

  Box Dimensions (LxWxH)	5.3 x 5.1 x 1.5"
