Product description

• 1303 HDR 13" Production Monitor
  • 1300 Series Announcement
  • Torture Test- HDR Production Monitors by SmallHD
  See beyond the restricted color and contrast of conventional monitoring with the SmallHD 1303 HDR 13" Production Monitor. Featuring HDR preview backed by a 10-bit Color Intelligence engine with calibration capabilities, the 1303 can display a large brightness range, encompassing log formats and other expanded-range picture styles. The 1500 cd/m², daylight-viewable, 1920x1080 Full HD resolution display panel can be driven by one of two SDI inputs or an HDMI input. Each input has a loop output for connecting other gear in-line without the need for a splitter. All functionality of this monitor is accessed via the innovative Page Builder OS. By implementing full aluminum construction and the provision for separately available user-replaceable polycarbonate screen protectors, SmallHD built this monitor to survive the rigors of production in studios and in the field.
  Page Builder OS
  • Originally featured in the 500 and 700-series models, and extrapolated for the Production Monitor series, the Page Builder OS is an intuitive graphical user interface (GUI) that puts all of the advanced functionality of the 1303 at your fingertips. Rather than have confusing menus, this GUI allows you to selectively apply monitoring tools such as waveforms, vectorscopes, multiview, and focusing aids to up to 4 different "pages". These pages can be easily flipped through using the joystick. The buttons on the front panel can also toggle monitoring tools on and off for each page.
  ColorFlow 3D LUT Processing
  • In order to keep your images consistent from production through to post-production, ColorFlow allows you to import 3D LUTs and display the treated image side-by-side with the untreated image to correctly gauge exposure while visualizing what is being recorded by the camera. Side-by-side preview can also be used with the HDR preview function. Separate LUT-treated images can be sent downstream over SDI and HDMI so you can have the 1303 display a log image or LUT-treated image, while the director or client monitors connected to the outputs can receive images treated with a different LUT. An image-capture function saves a still frame from the incoming video stream onto an SD card and also records the applied 3D LUT for post-production reference.
  Color Intelligence Engine
  • When a separately available color probe is connected to the monitor via USB, the SmallHD 1303 can automatically adjust a 10-bit 3D calibration LUT for maintaining accurate color reproduction over the life of the monitor.
  RapidRail Shoe-Mount System
  • Quickly secure and detach accessories such as wireless units to the rear of the monitor using standard shoe-mount rails. This saves time over traditional screw-mounted methods and keeps your setup clean and neat. If required these accessories can be powered straight off the monitor using the integrated 12V LEMO power output or the 3 USB ports.
  Power Options
  • Separately available V-mount or Gold-mount battery plates can be attached to the rear of the display. A mounted battery can power the monitor as well as attached accessories through the 12V LEMO connection. The USB ports on the rear of the monitor can also power accessories with a maximum draw of 0.5 amps per port.
  UPC: 850324007458
• Thin BNC Cable (12") At only 2.75mm in diameter this Thin BNC Cable from SmallHD will snake around nearly any component you have in your rig, perfect for use in compact camera setups with an EVF or on-camera monitor which uses SDI. UPC: 850246006447
• Thin BNC Cable (24") At only 2.75mm in diameter this Thin BNC Cable from SmallHD will snake around nearly any component you have in your rig, perfect for use in compact camera setups with an EVF or on-camera monitor which uses SDI. UPC: 857497005960
• Thin BNC Cable (48") At only 2.75mm in diameter this Thin BNC Cable from SmallHD will snake around nearly any component you have in your rig, perfect for use in compact camera setups with an EVF or on-camera monitor which uses SDI. UPC: 857497005977
• RapidRail Mount for 1/4"-20 Accessories Use the SmallHD RapidRail Mount for 1/4"-20 Accessories to quickly secure 1/4"-20 accessories to 1300, 1700, 2400, or 3200 series monitors that feature the RapidRail mounting system. Built-in cable strain relief protects your equipment from cable snags, and dual 1/4"-20 threads allow for the securing of many common monitoring accessories. UPC: 850246006645
• V-Mount Power Kit + Cheese Plate Provide power to your 1300, 1700, or 2400 series monitor with this SmallHD V-Mount Power Kit + Cheese Plate. This kit is comprised of a battery mount with a D-Tap to 4-pin XLR cable, and the required cheese plate for securing the battery mount to the monitor itself. See below for more information on the individual items included in this kit. UPC: 850246006942

• Screen Impact Protector for 1300 Series Monitors
• Three-Sided Sun Hood for 1300 Series Monitors
• C-Stand Mount for 1300 Series Monitors

• HDMI Cable (6')

• AC Power Cord

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• V-Mount Power Kit

• Pro Battery Cheese Plate

Also Includes

• SmallHD Matte Screen Protector for 1300 Series Monitor

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 1303 HDR 13" Production Monitor

  Panel Type	IPS
  Screen Size	13" / 33 cm
  Resolution	1920 x 1080
  Pixel Density	170 PPI
  Aspect Ratio	16:9
  Active Area	11.59 x 6.52
  Brightness	1500 cd/m²
  Contrast Ratio	1140:1
  Color Gamut	100% REC709
  Bit Depth	10-bit
  Viewing Angle	178°
  Backlight Type	LED (adjustable)

  Video I/O	Inputs 2 x SDI 1 x HDMI Outputs 2 x SDI 1 x HDMI
  Input Formats	SDI: 8-bit YCC 4:2:2 1080p23.98/24/25/29.97/30/50/59.94/60 1080PsF23.98/24/25/29.97/30 1080i50/59.94/60 (high-speed: 1080i100/119.88/120) 720p23.98/24/25/29.97/30/50/59.94/60 HDMI: 8-bit YCC 4:2:2, 8/10/12-bit RGB and YCC 4:4:4 1080p23.98/24/25/29.97/30/50/59.94/60 1080PsF23.98/24/25/29.97/30 1080i50/59.94/60 (high-speed: 1080i100/119.88/120) 720p23.98/24/25/29.97/30/50/59.94/60 576p50 (high-speed 576p100) 480p59.94/60 (high-speed 480p119.88/120) Audio: HDMI and SDI embedded
  Output Formats	SDI: 8-bit YCC 4:2:2 1080p23.98/24/25/29.97/30/50/59.94/60 1080PsF23.98/24/25/29.97/30 1080i50/59.94/60 (high-speed: 1080i100/119.88/120) 720p23.98/24/25/29.97/30/50/59.94/60 HDMI: 8-bit YCC 4:2:2, 8-bit RGB and YCC 4:4:4 1080p23.98/24/25/29.97/30/50/59.94/60 1080PsF23.98/24/25/29.97/30 1080i50/59.94/60 (high-speed: 1080i100/119.88/120) 720p23.98/24/25/29.97/30/50/59.94/60 576p50 (high-speed 576p100) 480p59.94/60 (high-speed 480p119.88/120)

  Data I/O	1 x SD card slot for LUTs, captured images, firmware updates
  Power	Inputs 1 x IEC AC input 1 x 4-pin XLR Outputs 1 x 12 VDC LEMO 3 x USB (0.5 A max output)
  Compliance	FCC, IC, CE, RoHS
  Operating Temperature	32 to 100°F / 0 to 37.8°C
  Storage Temperature	Not specified by manufacturer
  Dimensions	Not specified by manufacturer
  Weight	8 lb / 3.6 kg

  Box Dimensions (LxWxH)	18.0 x 13.5 x 9.5"

• Thin BNC Cable (12")

  Cable Length	12' / 3.7 m
  Weight	0.1 lb / 0.0 kg

  Box Dimensions (LxWxH)	7.05 x 4.95 x 0.55"

• Thin BNC Cable (24")

  Cable Length	2' / 0.6 m
  Weight	0.1 lb / 0.0 kg

  Box Dimensions (LxWxH)	7.4 x 5.3 x 0.5"

• Thin BNC Cable (48")

  Cable Length	4' / 1.2 m
  Weight	0.1 lb / 0.1 kg

  Box Dimensions (LxWxH)	2.5 x 1.5 x 0.85"

• RapidRail Mount for 1/4"-20 Accessories

  Mounting Threads	2 x 1/4"-20
  Dimensions	1.25 x 2.0 x 1.0" / 3.2 x 5.1 x 2.5 cm
  Weight	3 oz / 85 g

  Box Dimensions (LxWxH)	4.95 x 4.25 x 1.0"

• Screen Impact Protector for 1300 Series Monitors

  Box Dimensions (LxWxH)	12.25 x 8.8 x 0.65"

• Three-Sided Sun Hood for 1300 Series Monitors

  Box Dimensions (LxWxH)	12.6 x 8.95 x 1.45"

• C-Stand Mount for 1300 Series Monitors

  Box Dimensions (LxWxH)	5.8 x 4.05 x 2.35"

• V-Mount Power Kit + Cheese Plate

  Box Dimensions (LxWxH)	8.6 x 5.55 x 1.5"
