User Manual for SmallHD Cine Utility Pack for FOCUS 7 Monitor Click to enlarge the picture
Contents of the user manual for the SmallHD Cine Utility Pack for FOCUS
- Product category: Monitor Accessories SmallHD
- Brand: SmallHD
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for SmallHD Monitor Accessories
|
User manual for the SmallHD Cine Utility Pack for FOCUS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any SmallHD product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official SmallHD user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a SmallHD product will considerably shorten its lifespan!
|
Product description The Cine Utility Pack for FOCUS 7 Monitor from SmallHD provides a bundle of components for using and mounting the monitor with a cine-style rig. This bundle comprises a dual L-series battery kit, an L-Series battery dummy, a 7" StrongArm, a Magic Mount adapter, a 3' HDMI cable, and a 12" thin-gauge HDMI cable. A microfiber cleaning cloth and a matte screen protector are also included in this pack. - StrongArm 7 Articulating Arm The SmallHD StrongArm 7 is a 7" articulating monitor mount for SmallHD field monitors. It can attach directly to a camera's accessory shoe or 1/4"-20 thread mount. A single knob tightens all 3 articulating joints on the arm at once for maximum mobility and efficiency. UPC: 857497005045
- D-Tap to L-Series Dummy Battery Cable (32") SmallHD designed the D-Tap to L-Series Dummy Battery Cable as an extended power solution for their UltraBright monitors. The L-series dummy battery attaches to the back of the monitor while the D-Tap connector plugs into an optional brick battery or other D-Tap power source. The cable runs 32" long. UPC: 855534007946
- Matte Screen Protector for FOCUS 7 Monitor The SmallHD Matte Screen Protector is designed to protect your FOCUS 7 monitor from dust, dirt, and scratches. UPC: 811786030699
- HDMI Cable (3') The 3' HDMI Cable from SmallHD allows you to transmit high-quality digital audio and video on a single cable. This cable features a male HDMI connector on each end, and is compatible with a wide variety of devices such as SmallHD monitors. UPC: 857497005298
- Thin-Gauge Mini-HDMI Male Cable (12") Connect your portable devices to HDMI displays with the 12" Thin-Gauge Mini-HDMI Male Cable from smallHD. This RoHS-compliant cable allows you to transfer movies, photos, and videos from devices like smartphones, digital cameras, and video cameras with mini-HDMI connectors to view on your standard HDMI (type-A) television, projector, or computer monitor. UPC: 857497005915
- Microfiber Cleaning Cloth Made from a non-abrasive material, this Microfiber Cleaning Cloth from SmallHD is a safe option for cleaning glass surfaces and coatings on a monitor or camera. It measures approximately 7 x 7" and is easily stored in a bag or pocket when not in use. UPC: 850246006126
In the Box Bundle Items StrongArm 7 Articulating Arm cfxrcwyabrvcfcvxacfssvefzzw D-Tap to L-Series Dummy Battery Cable (32") Matte Screen Protector for FOCUS 7 Monitor HDMI Cable (3') Thin-Gauge Mini-HDMI Male Cable (12") Microfiber Cleaning Cloth
Also Includes - Dual L-Series Battery Kit
- Anti-Twist Magic Mount
Table of Contents
|
Upload User Manual
Have you got an user manual for the SmallHD Cine Utility Pack for FOCUS 7 Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - StrongArm 7 Articulating Arm
| Length | 7" (17.8 cm) | | Weight | 10 oz (283 g) | | | | Box Dimensions (LxWxH) | 4.6 x 3.7 x 1.75" | - D-Tap to L-Series Dummy Battery Cable (32")
| Length | 32" / 81 cm | | Weight | 6 oz / 170 g | | | | Box Dimensions (LxWxH) | 6.0 x 4.0 x 1.0" | - Matte Screen Protector for FOCUS 7 Monitor
| Dimensions and Weight | Not Specified by Manufacturer | - HDMI Cable (3')
| Connector 1 | HDMI Type-A Male | | Connector 2 | HDMI Type-A Male | | Cable Length | 3' / 0.9 m | | | | Box Dimensions (LxWxH) | 7.05 x 5.75 x 1.65" | - Thin-Gauge Mini-HDMI Male Cable (12")
| Connector 1 | HDMI Type-C Male | | Connector 2 | HDMI Type-A Male | | Cable Length | 12" / 30.5 cm | | Certifications | RoHS, as per Manufacturer | | Outer Diameter | 0.2" / 4.5 mm | | Weight | 0.6 oz / 17.0 g | | | | Box Dimensions (LxWxH) | 6.45 x 6.3 x 0.6" | - Microfiber Cleaning Cloth
| | | Box Dimensions (LxWxH) | 4.0 x 3.1 x 0.2" |
