Product description The HDP-RXS CAT-5 HDTV Receiver from Smart-AVI is one component in a paired transport system designed to transmit high-resolution HDTV, stereo audio, RS-232, and IR signals over CAT-5 Ethernet cable. This unit is the receiver and must be paired with a separately available transmitter unit. This model supports transmission distances up to 1000' (304.8m). - Uses easy-to-install, inexpensive CAT-5/5e/7/6/8 cable
- Extends output up to 1000' (304.8m)
- Supports high-resolution video up to 1920 x 1200
- HDTV-compatible (720p, 1080i, 1080p)
- Supports component video (YPbPr)
- Sends high-resolution HDTV, stereo audio, RS-232, and IR signals from one source to remote location using single CAT-5
- Compatible with line-level stereo audio signals
- High ground loop immunity
- Built-in power surge and transient protection
- Designated trimmer in the remote unit to compensate for cable length
- Compact metal case enclosure
- Transparent RS-232 and IR communication
In the Box Smart-AVI HDP-RXS CAT-5 HDTV Receiver Power Supply One-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Smart-AVI HDP-RXS CAT-5 HDTV Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSmart-AVI HDP-RXS Specs | Video | Bandwidth: 400MHz
Analog Signal Level: 1V
Impedance: 75 Ohms
Format: YPbPr analog component video | | Audio | Bandwidth: 20KHz
Signal Level: 1V
Impedance: 10K Ohms | | Cable | Type: CAT-5 UTP RIA
Connector: RJ-45 | | Connectors | Connector: 3 RCA
RS232: DB9 male/female, baud rate up to 115,000bps
IR: emitter output | | IR Signal | IR Frequency Range: 30 to 80KHz
Emitter Distance: up to 10'
Connector: 3.5mm stereo jack for emitter | | Power | Requirements: 5VDC @ 500mA
Connector: 5 x 2.1 DC jack | | Dimensions (HxWxD) | Not specified by manufacturer | | Weight | Not specified by manufacturer |
