User Manual for Smart-AVI HDP-TXS Component Video Audio RS232 IR CAT5 Transmitter Click to enlarge the picture
Contents of the user manual for the Smart-AVI HDP-TXS Component Video Audio RS232
- Product category: Video Extenders & Repeaters Smart-AVI
- Brand: Smart-AVI
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Smart-AVI Video Extenders & Repeaters
|
User manual for the Smart-AVI HDP-TXS Component Video Audio RS232 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Smart-AVI product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Smart-AVI user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Smart-AVI product will considerably shorten its lifespan!
|
Product description The HDP-TXS Component Video /Audio/RS232/IR CAT5 Transmitter from Smart-AVI is designed for use with the HDX-PRO receiver to extend video and audio signals up to 1,000' via user-friendly CAT5/5e/7/6/8 cabling. - Uses easy-to-install, inexpensive CAT5/5e/7/6/8 cable
- Extends output up to 1,000 feet
- Supports high-resolution video up to 1920 x 1200
- HDTV compatible (720p, 1080i, 1080p)
- Supports Component Video (YPbPr)
- Sends high-resolution HDTV, stereo audio, RS-232 and IR signals from one source to remote location using single cat5
- Compatible with line level stereo audio signals
- High ground loop immunity
- Built-in power surge and transient protection
- Designated trimmer in the remote unit to compensate for cable length
- Compact metal case enclosure
- Transparent RS-232 and IR communication
In the Box Smart-AVI HDP-TXS Component Video /Audio/RS232/IR CAT5 Transmitter XTP-TX CCVGAMM06 VGA Cable PS5VD1A Power Supply Table of Contents
|
Upload User Manual
Have you got an user manual for the Smart-AVI HDP-TXS Component Video Audio RS232 IR CAT5 Transmitter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSmart-AVI HDP-TXS Specs | Maximum Operating Distance | 1000' | | Cable | CAT5/5e/7/6/8 | | Connectors | Video: Component YPbPr RCA x 3
Audio: RCA x 2
Audio: 3.5mm stereo jack Output: RJ45
Data: DB9
IR: 3.5mm stereo jack | | Power | 5VDC | | Dimensions (WxHxD) | Not specified by the manufacturer | | Weight | Not specified by the manufacturer | | | | Package Weight | 1.0 lb | | Box Dimensions (LxWxH) | 7.8 x 5.4 x 4.3" |
