Product description The HDX-W100 HDMI over Cat5e/6 Wall Plate Receiver from Smart-AVI receives HDMI signals from 150' away via a single Cat5e/6 cable. The receiver supports high-resolution video up to 1080p 60 Hz, and features bidirectional IR communication so you can easily control the video source. The unit is powered via the included 12V power adapter. - Accepts HDMI signals via a single Cat5e/6 cable
- Supports uncompressed HD video up to 1080p @ 60 Hz
- HDMI 1.3 and HDCP compliant
- Supports bidirectional IR communication
- Supports automatic EDID callback
- Compatible with DVI-D with converter
- Cascadable for additional extensions
- VESA DDC and hot swap technology (HPD)
- Power over Ethernet (PoE)
UPC: 813280021944 In the Box Smart-AVI HDX-W100 HDMI over Cat5e/6 Wall Plate Receiver PS12V2A Power Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Smart-AVI HDX-W100 HDMI over Cat5e 6 Wall Plate Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSmart-AVI HDX-W100RX Specs | Video Resolution | Up to 1080p @ 60 Hz | | Audio Format | Up to PCM 8-channel, Dolby Digital, TrueHD, and DTS-HDMaster Audio | | IR Range | 38 kHz | | Video Bandwidth | 4.95 Gbps | | Input Video Signal | 1.2 Vpp | | Input DDC Signal | 5 Vpp | | Input Connectors | RJ45
3.5 mm Mini jack, IR receiver
12 VDC power input barrel | | Output Connectors | 3.5 mm Mini jack, IR emitter
19-Pin HDMI type A | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 140°F (-20 to 60°C) | | Compliance | FCC, CE, RoHS | | | | Package Weight | 0.9 lb | | Box Dimensions (LxWxH) | 7.7 x 5.4 x 4.4" |
