Product description The RKT16-HDX100S 16-Port HDMI over CAT5e/6 Extender from Smart-AVI extends 16 HDMI video signals to a remote location up to 150' away. You can consolidate up to 16 workstation computers into one location using the HDX-RX100 HDMI extender receiver unit (sold separately). This 16-port unit is fully compatible with MAC, PC and LINUX HDMI standards. Up to 16 displays can be extended from a rack. This extender features 16 inputs, 16 outputs, and one power supply. - Supports up to 16 HDMI sources
- Supports 1920 x 1200 60 Hz WUXGA resolution
- Extends up to 150' with CAT5e/CAT6 STP cables
- Zero pixel loss with TMDS signal correction
- Compatible with MAC, PC and LINUX HDMI
- Local HDMI output for each port
- HDMI 1.3 and HDCP compliance
- Compatible with all major DVD players
- Data recovery for digital video
- Applications
-
- Home theater
- Corporate/educational presentations
- Call centers
- Industrial (long-range workstation isolation)
- Information terminals/kiosks
- Airport installations (air traffic control/passenger information)
- Educational environments with remote displays
In the Box Smart-AVI RKT16-HDX100S 16-Port HDMI over CAT5e/6 Extender (150') - Limited 1-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Smart-AVI RKT16-HDX100S 16-Port HDMI over CAT5e 6 Extender in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSmart-AVI RKT16-HDX100S Specs | Format | HDMI | | Distance | Up to 150' (45.7 m) | | Maximum Pixel Clock | 165 MHz | | Connectors | 16 x HDMI input, female
16 x RJ45
16 x HDMI output, female
1 x Power | | Resolution | Up to 1920 x 1200 @ 60 Hz | | DDC | 5 V p-p, TTL | | Input Equalization | Automatic | | Cable Length | Up to 20' (6.1 m) | | Power | 110 - 240 VAC | | Operating Temperature | 32 to 131°F (0 to 55°C) | | Storage Temperature | -4 to 185°F (-20 to 85°C) | | Humidity | Up to 95% | | Dimensions | 17 x 3.5 x 3.25" (43.2 x 8.9 x 8.3 cm) | | Weight | 10 lb (4.5 kg) |
