Product description The Smart-AVI Super Range SDX-Plus DVI-D, USB Keyboard & Mouse, & RS232 IR Extender is capable of sending DVI-D signals up to 400’ over a single CAT5/5e/6 cable. HDBaseT technology requires a CAT6 shielded cable to go a short distance. This SDX-Plus Extender also allows for USB keyboard and mouse, RS232, and IR extension, giving you the ability to control your displays or devices remotely. - Extends DVI-D up to 400' (120m) from the source
- Data recovery for digital video
- Supports up to 1920 x 1200 digital video resolution
- USB keyboard & mouse extension
- Uncompressed video HDBaseT technology
- IR and RS232 extension allows for remote control of displays
- External power adapter for transmitter and receiver units
- Compatible with Windows, Mac, and Linux operating systems
- Applications: Digital signage, security, PC networking, conference center systems, point of sale, camera surveillance, video phones, control room systems, recording studios, and PC KVM extension
UPC: 813280015516 In the Box Smart-AVI Super Range SDX-Plus DVI-D, USB Keyboard & Mouse, & RS232 IR Extender SDX-Plus-TX Transmitter SDX-Plus-RX Receiver 2 x PS5VDC2A Wall Mount Power Supply Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Smart-AVI Super Range SDX-Plus DVI-D, USB Keyboard & Mouse, & RS232 IR Extender in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSmart-AVI SDX-PLUS-S Specs | Format | Video: DVI-D Single Line | | Maximum Pixel Clock | Video: 165 MHz | | Interface | Video
Input (Transmitter): 1 x DVI-D 29-pin female
Output (Receiver): 1 x DVI-D 29-pin female
USB
Input (Transmitter): 1 x USB Type B (female)
Output (Receiver): 2 x USB Type A (female)
RS232
Input (Transmitter): DB9 (female)
Output (Receiver): DB9 (female)
IR
Input (Transmitter): 3.5 mm (female)
Output (Receiver): 3.5 mm (female) | | Resolution | Video: Up to 1920 x 1200 @ 60 Hz | | DDC | Video: 5 Vpp (TTL) | | Input Equalization | Video: Automatic | | Cable Length | Video
Input: Up to 20.0' (6.1 m)
Output: Up to 20.0' (6.1 m) | | Signal Type | USB: OHCI/UHCI (USB 1.1) | | Speed | RS232: @ 115 kb/s | | Frequency Response | IR: 30 to 80 kHz | | Power | External 100 to 240 VAC/5 VDC, 4 A @ 20 W | | Temperature | Operating: 32 to 131°F (0 to 55°C)
Storage: -4 to 185°F (-20 to 85°C) | | Humidity | Up to 95% | | Dimensions (W x H x D) | 5.13 x 1.00 x 3.63" (130.3 x 25.40 x 92.20 mm) | | Weight | 0.50 lb (0.23 kg) | | | | Package Weight | 2.0 lb | | Box Dimensions (LxWxH) | 9.0 x 8.0 x 4.0" |
