User Manual for Solid State Logic X-Rack Stereo Dynamics Module Click to enlarge the picture
Contents of the user manual for the Solid State Logic X-Rack Stereo Dynamics
- Product category: Preamp Accessories Solid State Logic
- Brand: Solid State Logic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Solid State Logic Preamp Accessories
|
User manual for the Solid State Logic X-Rack Stereo Dynamics contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Solid State Logic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Solid State Logic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Solid State Logic product will considerably shorten its lifespan!
|
Product description The X-Rack Stereo Dynamics Module from Solid State Logic is an expansion module designed for the X-Rack rack system. The module is a stereo version of the SSL channel dynamics. It features independent compressor/limiter and expander/gate circuits to provide familiar Superanalogue level control tools for recording and mixing.
The compressor can switch between RMS and Peak sensing, and also offers a Hard Knee mode to provide a wide range of leveling control. The secondary circuit functions as either a noise gate or an expander to enhance creative sound design possibilities. The module has a +4dBu operating level and offers balanced stereo line 1/4" input and output connectors. A 1/4" mono external key input allows multiple modules to be linked. - Designed for the X-Rack rack system
- Independent compressor/limiter and expander/gate circuits provide familiar Superanalogue level control tools for recording and mixing
- The compressor can switch between RMS and Peak sensing, and also offers a Hard Knee mode to provide a wide range of levelling control with dedicated gain reduction metering
- The secondary circuit functions as either a noise gate or an expander to enhance creative sound design possibilities
- The module has a +4dBu operating level and offers balanced stereo line 1/4" input and output connectors
- A 1/4" mono external key input allows multiple modules to be linked
In the Box Solid State Logic X-Rack Stereo Dynamics Module 1-Year Limited Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Solid State Logic X-Rack Stereo Dynamics Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSolid State Logic 729728X1 Specs | Compressor | Ratio: 1 to Infinity, Variable
Threshold: +10dB to -30dB, Variable
Attack Time: Auto-Sensing, Switchable to 1mS
Release Time: 0.1 to 4 seconds, Variable | | Expander | Ratio: 0 to 40dB, Variable
Threshold: -30dB to +10dB, Variable
Attack Time: Auto-Sensing, Switchable to 150µS
Hold Time: 0 to 4 seconds, Variable
Release Time: 0.1 to 4 seconds, Variable | | Total Harmonic Distortion (THD) | < 0.01% at 1kHz (+10dBu)
Fast Attack Mode: < 0.3% at 1kHz, < 0.05% at 10kHz
Slow Attack Mode: < 0.03% at 1kHz, < 0.05% at 10kHz | | Headroom | > +26dBu | | Frequency Response | 20Hz - 20kHz ±0.2dB, -3dB at 150kHz | | Operating Temperature | 41 to 86°F (5 to 30°C) (20 to 80% Relative Humidity) | | Dimensions (HxWxD) | 6.75 x 1.4 x 10.9" (171 x 35 x 275mm) (Including Knobs and Connectors) | | Weight | 9.5 oz (260g) |
